Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano Dura Ace Di2
Wheelset
Reserve 37TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 497 | 522 | 547 | 572 | 597 | 622 |
| Reach (mm) | 363 | 371 | 380 | 389 | 398 | 407 |
| Effective top tube (mm) | 516 | 531 | 548 | 564 | 581 | 598 |
| Seat tube (mm) | 431 | 464 | 492 | 517 | 542 | 567 |
| Head tube (mm) | 83 | 105 | 129 | 154 | 179 | 205 |
| Standover (mm) | 693 | 723 | 753 | 777 | 802 | 827 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73 | 73 | 73 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73 | 73 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 974 | 974 | 977 | 993 | 1,011 | 1,028 |
| Fork offset (mm) | 57 | 51 | 45 | 45 | 45 | 45 |
| Trail (mm) | 57.3 | 57.1 | 57.2 | 57.2 | 57.2 | 57.2 |
Frame Details
Frame Weight
This frame weighs 651g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Tapered R5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano Dura Ace Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Dura Ace, R9270, 12 speed
Front Derailleur
Shimano Dura-Ace Di2 FD-R9250 (Official)
Rear Derailleur
Shimano Dura Ace, R9250, 12 speed, Direct Mount
Cassette
Shimano Dura-Ace CS-R9200 (Official)
Cranks
Shimano Dura-Ace FC-R9200
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
Ceramic Speed, BBright for 24mm spindle
Chain
Shimano Dura-Ace CN-M9100 12-speed (Official)
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Rear: Reserve 37TA, Zipp ZR1 SS, 12x142mm,Front: Reserve 34TA, Zipp ZR1 SS, 12x100mm
Front Wheel Depth
34mm
Rear Wheel Depth
37mm
Tires
Corsa Pro TLR 700x26mm
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano Dura-Ace
Brake Rotors
160 mm front / 140 mm rear Centerlock configuration (Official Retailer Listed). Uses premium RT-CL900 ice-technologies freeza rotors
Other Components
Saddle
Prologo Scratch M5 PAS Nack
Seatpost
Cervélo SP24 Carbon
Handlebars
Cervélo HB13 Carbon, 31.8mm clamp
