Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano Dura-Ace Di2
Wheelset
Reserve 57TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 cm | 51 cm | 54 cm | 56 cm | 58 cm | 61 cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 496 | 519 | 542 | 565 | 588 | 611 |
| Reach (mm) | 367 | 376 | 384 | 392 | 401 | 409 |
| Effective top tube (mm) | 520 | 535 | 550 | 565 | 581 | 595 |
| Head tube (mm) | 69 | 87 | 109 | 130 | 157 | 173 |
| Standover (mm) | 715 | 736 | 754 | 782 | 813 | 840 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73.50 | 73.50 | 73.50 |
| Seat angle (°) | 73 | 73 | 73 | 73 | 73 | 73 |
| Chainstay (mm) | 405 | 405 | 405 | 405 | 405 | 405 |
| Wheelbase (mm) | 973 | 980 | 984 | 993 | 1,010 | 1,023 |
| BB drop (mm) | 72.5 | 72.5 | 70 | 70 | 67.5 | 67.5 |
Frame Details
Frame Weight
This frame weighs 703g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Bayonet S5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano Dura-Ace Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Dura-Ace, R9270
Front Derailleur
Shimano Dura-Ace Di2 FD-R9250.
Rear Derailleur
Shimano Dura-Ace, R9250
Cassette
Shimano Dura-Ace 11-34T
Cranks
Shimano Dura-Ace FC-R9200
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
Ceramic Speed SL, BBright for 24mm spindle
Chain
Shimano CN-M9100, 12-speed (Inferred/Retailer-listed matching the standard Dura-Ace/XTR level 12-speed spec).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
F: Reserve 57TA, DT Swiss 180, R: Reserve 64TA, DT Swiss 180, 12x142mm
Front Wheel Depth
52mm
Rear Wheel Depth
63mm
Tires
Vittoria Corsa Pro TLR G2.0 700x29c
Tire Type
Tubeless
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano Dura-Ace
Brake Rotors
160 mm Front / 160 mm Rear. (The proprietary Bayonet S5 fork features a native flat mount configured exclusively for a 160 mm rotor, making a down-size to a 140 mm front rotor impossible)
Other Components
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Carbon
Seatpost
Cervélo SP34 Carbon
Handlebars
Cervélo HB19 Carbon
