Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano Ultegra Di2
Wheelset
Reserve 57TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 cm | 51 cm | 54 cm | 56 cm | 58 cm |
|---|---|---|---|---|---|
| Sizing | |||||
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 496 | 519 | 542 | 565 | 588 |
| Reach (mm) | 367 | 376 | 384 | 392 | 401 |
| Effective top tube (mm) | 520 | 535 | 550 | 565 | 581 |
| Seat tube (mm) | 437 | 466 | 494 | 522 | 547 |
| Head tube (mm) | 69 | 87 | 109 | 130 | 157 |
| Standover (mm) | 707.5 | 729.2 | 747.4 | 775.3 | 805.9 |
| Handling | |||||
| Head angle (°) | 71 | 72 | 73 | 73.50 | 73.50 |
| Seat angle (°) | 73 | 73 | 73 | 73 | 73 |
| Chainstay (mm) | 405 | 405 | 405 | 405 | 405 |
| Wheelbase (mm) | 973 | 974 | 975 | 982 | 999 |
| Fork offset (mm) | 58 | 52 | 46 | 43 | 43 |
Frame Details
Frame Weight
This frame weighs 1030g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Bayonet S5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano Ultegra Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Ultegra, R8170
Front Derailleur
Shimano Ultegra Di2 FD-R8150.
Rear Derailleur
Shimano Ultegra, R8150
Cassette
Shimano Ultegra CS-R8100.
Cranks
Shimano Ultegra FC-R8100
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
FSA, BBright thread together for 24mm spindle
Chain
Shimano XT/Ultegra CN-M8100 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
F: Reserve 57TA, DT Swiss 240, 12x100mm R: Reserve 64TA, DT Swiss 240, 12x142mm
Front Wheel Depth
52mm
Rear Wheel Depth
63mm
Tires
Vittoria Corsa Pro TLR G2.0 700x29c
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
Shimano Ultegra
Brake Rotors
160 mm diameter front and rear
Other Components
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Ti
Seatpost
Cervélo SP34 Carbon
Handlebars
Cervélo HB19 Carbon
