Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
SRAM Red AXS
Wheelset
Reserve 57TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 cm | 51 cm | 54 cm | 56 cm | 58 cm | 61 cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 152–160 cm | 159–168 cm | 168–174 cm | 174–180 cm | 180–185 cm | 185–193 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 496 | 519 | 542 | 565 | 588 | 608 |
| Reach (mm) | 367 | 376 | 384 | 392 | 401 | 409 |
| Effective top tube (mm) | 520 | 535 | 550 | 565 | 580 | 595 |
| Head tube (mm) | 64 | 87 | 110 | 134 | 157 | 173 |
| Standover (mm) | 712 | 736 | 763 | 789 | 813 | 822 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73.50 | 73.50 | 73.50 |
| Seat angle (°) | 73 | 73 | 73 | 73 | 73 | 73 |
| Chainstay (mm) | 405 | 405 | 405 | 405 | 405 | 405 |
| Wheelbase (mm) | 973 | 980 | 984 | 993 | 1,009 | 1,013 |
| Fork offset (mm) | 58.5 | 52.3 | 46.2 | 43.5 | 43.5 | 43.5 |
| Trail (mm) | 56.1 | 56.5 | 56.4 | 56.2 | 56.2 | 56.2 |
Frame Details
Frame Weight
This frame weighs 124g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Bayonet S5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Red AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Red AXS E1
Front Derailleur
SRAM RED AXS, braze-on (Official).
Rear Derailleur
SRAM Red AXS E1
Cassette
SRAM RED, XG-1290 (Official).
Cranks
SRAM RED AXS (165mm to 175mm by size)
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB Ceramic, BBright
Chain
SRAM RED, 12-speed flattop (Official).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
F: Reserve 57TA, DT Swiss 180, R: Reserve 64TA, DT Swiss 180, 12x142mm
Front Wheel Depth
57mm
Rear Wheel Depth
64mm
Tires
Vittoria Corsa Pro TLR G2.0 700x29c
Tire Type
Tubeless
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Red AXS
Brake Rotors
160 mm front and 160 mm rear (Official / Wheelbase UK detailed spec). Uses SRAM Paceline X rotors
Other Components
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Carbon
Seatpost
Cervélo SP34 Carbon
Handlebars
Cervélo HB19 Carbon
