The TrekTrek Madone SL 6 Di2 Gen 6, a Road bike released in 2023, priced at £4900. It weighs approximately 8.70kg, balancing performance and efficiency. It features a frame made of Carbon Fiber and a fork constructed from Carbon Fiber. The bike is equipped with a Shimano 105 R7150 Di2 groupset (Electric Shifting: Yes). It uses Disc Brake braking for confident stopping power. Rolling on a Bontrager Aeolus Elite 50 wheelset, it features a Praxis, T47 threaded, internal bearing bottom bracket for drivetrain efficiency. It uses Semi Routed cable routing for a cleaner look and improved aerodynamics. It supports tires up to 28 mm, offering flexibility for comfort or off-road use. This bike is UCI compliant, meaning it can be used in officially sanctioned races. It comes with a lifetime warranty. Curious how it stacks up against similar bikes? Compare below...
The website average for Road bikes is 8.57 kg. This bike is 0.12 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano 105 R7150 Di2
Wheelset
Bontrager Aeolus Elite 50
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 28 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
4750525456586062
This frame comes in 8 sizes, this is 2.45 more sizes than the website average.
Handebar Sizes Available
Unknown
Crank Arm Sizes Available
Unknown
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Madone KVF full carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105 R7150 Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano 105 R7170, 12-speed
Front Derailleur
Shimano 105 R7150 Di2, braze-on, down swing
Rear Derailleur
Shimano 105 R7150 Di2, 36T max cog
Cassette
Shimano 105 7100, 11-34, 12-speed
Cranks
Shimano 105 R7100
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Praxis, T47 threaded, internal bearing
Chain
Shimano SLX M7100, 12-speed
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Bontrager Aeolus Elite 50
Front Wheel Depth
50mm
Rear Wheel Depth
50mm
Tires
Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25 mm
Tire Type
Tubeless
Max Tire Size: 28 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105 hydraulic disc
Brake Rotors
Shimano RT70, CentreLock, 160 mm
Other Components
Saddle
Bontrager Aeolus Comp, steel rails, 145 mm width
Seatpost
Madone aero carbon internal seat mast cap
Handlebars
Bontrager Elite Aero VR-CF
Bar Tape
Bontrager Supertack Perf tape
Manufactures Description
Madone SL 6 Disc gives you the advanced aerodynamic performance and all-around ride quality of our ultimate race bike at a great value. It has Shimano's all-new wireless 105 Di2 electronic drivetrain, aero wheels, a road-smoothing IsoSpeed decoupler, powerful hydraulic disc brakes and a sleek look that screams for speed.
Madone SL 6 Disc gives you the advanced aerodynamic performance and all-around ride quality of our ultimate race bike at a great value. It has Shimano's all-new wireless 105 Di2 electronic drivetrain, aero wheels, a road-smoothing IsoSpeed decoupler, powerful hydraulic disc brakes and a sleek look that screams for speed.
