Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 5 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano 105 Di2
Wheelset
DT Swiss ARC 1400 (50mm)
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Aluminium
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 50 52 54 56 58 60This frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 | 50 | 52 | 54 | 56 | 58 | 60 |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 521 | 530 | 539 | 549 | 565 | 584 | 598 |
| Reach (mm) | 372 | 379 | 385 | 387 | 392 | 399 | 407 |
| Effective top tube (mm) | 497 | 511 | 525 | 544 | 559 | 572 | 584 |
| Seat tube (mm) | 460 | 465 | 475 | 485 | 500 | 520 | 535 |
| Head tube (mm) | 120 | 125 | 133 | 145 | 160 | 180 | 195 |
| Standover (mm) | 733 | 740 | 749 | 760 | 774 | 794 | 808 |
| Handling | |||||||
| Head angle (°) | 71.25 | 72.50 | 73 | 73 | 73.50 | 73.50 | 73.50 |
| Seat angle (°) | 76.50 | 76 | 75.50 | 74 | 73.50 | 73.50 | 73.50 |
| Chainstay (mm) | 405 | 405 | 405 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 969 | 968 | 973 | 984 | 988 | 1,001 | 1,013 |
Frame Details
Frame Weight
This frame weighs 1450g
Frame Material
Aluminium
Forks
Standert monocoque carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano 105 Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano 105 Di2
Front Derailleur
and Rear.
Rear Derailleur
Shimano 105 Di2
Cassette
11-30T / 11-34T (Shimano) or 10-28T / 10-33T (SRAM)
Cranks
Shimano R8100 / SRAM Force DUB Crankset
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
T-47
Chain
Shimano Ultegra CN-M8100.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
DT Swiss ARC 1400 (50mm)
Front Wheel Depth
50mm
Rear Wheel Depth
50mm
Tires
Schwalbe Pro One Evo TLR
Tire Type
Tubeless
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105
Brake Rotors
Uses a flat-mount standard equipped with a 160mm rotor up front and a 140mm rotor in the rear as the standard factory configuration. The frame's maximum rear rotor support peaks at 160mm
Other Components
Saddle
Fizik Vento Argo R1 140mm
Seatpost
Zipp SC SL
Handlebars
Deda Superzero RS Carbon
Bar Tape
Fizik Vento Microtex 2mm
