Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.68 kg
The website average for Road bikes is 8.56 kg. This bike is 0.11 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano 105 R7020
Wheelset
DT Swiss R470 rim
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Aluminium
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 49 cm | 52 cm | 54 cm | 56 cm | 58 cm | 61 cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 508 | 520 | 537 | 558 | 584 | 605 |
| Reach (mm) | 378 | 383 | 387 | 398 | 405 | 411 |
| Effective top tube (mm) | 509 | 532 | 544 | 563 | 577 | 595 |
| Seat tube (mm) | 470 | 495 | 510 | 530 | 550 | 570 |
| Head tube (mm) | 105 | 115 | 133 | 153 | 178 | 201 |
| Standover (mm) | 735 | 755 | 775 | 798 | 823 | 842 |
| Handling | ||||||
| Head angle (°) | 71.75 | 72.50 | 73 | 73.50 | 74 | 73.50 |
| Seat angle (°) | 75.50 | 74 | 74 | 73.50 | 73.50 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 974 | 977 | 981 | 992 | 1,002 | 1,013 |
| Fork offset (mm) | 47 | 47 | 44 | 44 | 44 | 44 |
| Trail (mm) | 63 | 58 | 58 | 55 | 52 | 55 |
Frame Details
Frame Weight
This frame weighs 1400g
Frame Material
Aluminium
Forks
FACT Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105 R7020
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105 R7020, hydraulic disc
Front Derailleur
Shimano 105 R7000, braze-on.
Rear Derailleur
Shimano 105 R7000 GS, medium cage, 11-speed
Cassette
Shimano 105 R7000, 11-28t.
Cranks
Shimano 105 R7000
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Threaded BSA BB
Chain
KMC X11 Extra Lightweight.
Wheel & Tire Details
Wheelset Name
DT Swiss R470 rim
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
Turbo Pro, BlackBelt protection, 700x26mm
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105, Hydraulic disc
Brake Rotors
160mm front and 160mm rear Shimano SM-RT70 Centerlock disc rotors (Review-measured / Industry build standard)
Other Components
Saddle
Body Geometry Power Sport, steel rails
Seatpost
2021 S-Works Tarmac Carbon seat post
Handlebars
Specialized Shallow Drop
Bar Tape
Supacaz Super Sticky Kush
