Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano Claris 2000
Wheelset
Axis Sport Disc
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Aluminium
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: No
You can't use for official races
Sizing & Geometry
Frame Sizes
44 49 52 54 56 58 61This frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 44cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 519 | 536 | 552 | 569 | 590 | 610 | 643 |
| Reach (mm) | 356 | 359 | 364 | 370 | 378 | 386 | 392 |
| Effective top tube (mm) | 493 | 512 | 527 | 541 | 558 | 576 | 600 |
| Seat tube (mm) | 430 | 450 | 480 | 510 | 530 | 550 | 580 |
| Head tube (mm) | 110 | 125 | 140 | 155 | 175 | 195 | 225 |
| Standover (mm) | 715 | 737 | 761 | 787 | 805 | 823 | 851 |
| Handling | |||||||
| Head angle (°) | 69.50 | 70.30 | 71 | 71.80 | 72.30 | 72.80 | 73 |
| Seat angle (°) | 75.30 | 74.80 | 74.30 | 73.30 | 73.30 | 73.30 | 73.30 |
| Chainstay (mm) | 420 | 420 | 422 | 425 | 425 | 427 | 427 |
| Wheelbase (mm) | 984 | 993 | 1,000 | 1,004 | 1,014 | 1,029 | 1,049 |
| Fork offset (mm) | 47 | 47 | 47 | 47 | 47 | 47 | 47 |
| Trail (mm) | 81 | 75 | 71 | 65 | 62 | 59 | 58 |
Frame Details
Frame Weight
This frame weighs 1375g
Frame Material
Aluminium
Forks
Specialized FACT full carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano Claris 2000
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano Claris 2000, 8-speed
Front Derailleur
Shimano Claris Braze-on
Rear Derailleur
Shimano Claris, 8-speed
Cassette
SunRace, 8-speed
Cranks
Shimano Claris R200 (or non-series)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano 68mm threaded
Chain
KMC X8 with reusable Missing Link™
Wheel & Tire Details
Wheelset Name
Axis Sport Disc
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
Specialized Roadsport, 700X30c
Tire Type
Clincher
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Tektro MD-550 Mechanical Disc
Brake Rotors
160mm front and 160mm rear rotors across both mechanical and hydraulic tiers
Other Components
Saddle
Body Geometry Bridge Saddle, steel rails
Seatpost
Alloy, 2-bolt Clamp
Handlebars
Specialized Shallow Drop
Bar Tape
Specialized S-Wrap
