Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Gravel
The style of riding intended for this bike
Bike Spec
Weight: 10.1 kg
The website average for Gravel bikes is 9.44 kg. This bike is 0.65 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano GRX
Wheelset
DT Swiss G1800
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 53 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider inseam | 68–73 cm | 73–78 cm | 78–83 cm | 83–88 cm | 88–93 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 546 | 557 | 576 | 595 | 623 |
| Reach (mm) | 375 | 390 | 395 | 405 | 420 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Focus Carbon Technology Disc with triple mounts
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano GRX
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano GRX ST-RX610, 12-speed
Front Derailleur
Shimano GRX RX820 (braze-on with clamp adapter) (Official)
Rear Derailleur
Shimano GRX RD-RX820, 12-speed
Cassette
Shimano 105 R7100, 12-speed (Official)
Cranks
Shimano GRX RX610
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Pressfit Road BB86
Chain
Shimano Deore M6100, 12-speed with Quick-Link (Official)
Wheel & Tire Details
Wheelset Name
DT Swiss G1800, 25 mm height
Front Wheel Depth
20mm
Rear Wheel Depth
25mm
Tires
WTB Riddler, 700 x 45C, folding | WTB Riddler, 700 x 45C, folding
Tire Type
Tubeless
Max Tire Size: 53 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano CN-LG50 | Shimano CN-LG50
Brake Rotors
Shimano RT54 CenterLock rotors
Other Components
Saddle
Prologo Akero
Seatpost
Lee Chi SP-926, Carbon Fiber, 27,2mm, set-back: 0mm
Handlebars
FOCUS JD RA85, 31,8 mm, drop: 116 mm, reach: 74 mm, flare: 10°
Bar Tape
FOCUS Bartape SL
