Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.6 kg
The website average for Road bikes is 8.56 kg. This bike is 0.03 kg over the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival XPLR AXS
Wheelset
Newmen Performance X.R.25
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
50 53 56 58 61This frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 50cm | 53cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider height | 165–170 cm | 170–175 cm | 176–182 cm | 182–186 cm | 185–195 cm |
| Frame geometry | |||||
| Stack (mm) | 520 | 544 | 570 | 589 | 613 |
| Reach (mm) | 381 | 383 | 390 | 396 | 406 |
| Effective top tube (mm) | 525 | 541 | 560 | 575 | 595 |
| Seat tube (mm) | 470 | 500 | 530 | 550 | 580 |
| Head tube (mm) | 100 | 125 | 150 | 170 | 195 |
| Standover (mm) | 759 | 787 | 814 | 831 | 857 |
| Handling | |||||
| Head angle (°) | 71.50 | 71.50 | 72 | 72 | 72.50 |
| Seat angle (°) | 74.50 | 74 | 73.40 | 73 | 72.50 |
| Chainstay (mm) | 423 | 423 | 425 | 425 | 425 |
| Wheelbase (mm) | 1,006 | 1,017 | 1,025 | 1,035 | 1,051 |
| Fork offset (mm) | 45 | 45 | 45 | 45 | 45 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
C:62® Advanced Twin Mold Technology, Internal Cable Routing, Integrated Seat Post Clamp, Flat Mount Disc, AXH, 12x142mm
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival XPLR AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTap AXS™
Front Derailleur
None
Rear Derailleur
SRAM Rival XPLR AXS™, 12-Speed, Electronic Shifting System
Cassette
SRAM XG-1250 (12-speed).
Cranks
SRAM Rival 1 Wide, DUB
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB Road Wide, Pressfit
Chain
SRAM Rival D1, 12-speed flattop profile.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Newmen Performance X.R.25, 28/28 Spokes, 12x100mm / 12x142mm, Tubeless Ready
Front Wheel Depth
25mm
Rear Wheel Depth
25mm
Tires
Schwalbe X-One Allround, PerfL, Kevlar, 33-622
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Rival AXS™ (160/160)
Brake Rotors
160 mm Front / 160 mm Rear configuration using SRAM Paceline or standard AXS Centerline center-lock rotors
Other Components
Saddle
ACID Nuance Pro
Seatpost
Newmen Evolution, 27.2mm
Handlebars
CUBE Compact Race Bar
