Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.8 kg
The website average for Road bikes is 8.56 kg. This bike is 0.76 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano 105
Wheelset
DT Swiss R470
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 44 | 49 | 52 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | — | 514 | 527 | 544 | 565 | 591 | 612 |
| Reach (mm) | — | 375 | 380 | 384 | 395 | 402 | 408 |
| Effective top tube (mm) | — | 508 | 531 | 540 | 562 | 577 | 595 |
| Seat tube (mm) | 481 | 431 | 462 | — | 504 | 532 | 567 |
| Head tube (mm) | — | 109 | 120 | 137 | 157 | 184 | 204 |
| Standover (mm) | — | 705 | 728 | 748 | 769 | 796 | 824 |
| Handling | |||||||
| Head angle (°) | — | 71.75 | 72.50 | 73 | 73.50 | 73.50 | 74 |
| Seat angle (°) | — | 75.50 | 74 | 74 | 73.50 | 73.50 | 73 |
| Wheelbase (mm) | — | 973 | 975 | 978 | 991 | 1,005 | 1,012 |
| Trail (mm) | — | 63 | 58 | 58 | 55 | 55 | 52 |
Frame Details
Frame Weight
This frame weighs 699g
Frame Material
Carbon Fiber
Forks
FACT Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105
Front Derailleur
Shimano 105 R7100, Braze-on fitting.
Rear Derailleur
Shimano 105
Cassette
Shimano 105 R7100, 12-speed.
Cranks
Shimano 105 FC-R7100 Hollowtech II
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Threaded BSA BB
Chain
Shimano SLX M7100, 12-speed with Quick-Link (Stock configuration utilizes the cross-compatible mountain bike line chain for factory delivery optimized to the 12-speed ramp shape).
Wheel & Tire Details
Wheelset Name
DT R470
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
Turbo Pro
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105, Hydraulic disc
Brake Rotors
160mm front rotor / 140mm rear rotor (Shimano Centerlock RT70 or equivalent standard configuration)
Other Components
Saddle
Body Geometry Power Sport
Seatpost
Roval Alpinist Carbon Seatpost
Handlebars
Specialized Shallow Drop
Bar Tape
Supacaz Super Sticky Kush
