Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano 105
Wheelset
Giant P-R2 Disc wheelset
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Aluminium
Max Tire Size: 38 mm
This is the max tire size you can use
UCI Approved: No
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M M/L L XLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | ML | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 524 | 541 | 563 | 577 | 596 | 615 |
| Reach (mm) | 372 | 375 | 378 | 384 | 393 | 401 |
| Effective top tube (mm) | 515 | 530 | 545 | 560 | 575 | 595 |
| Seat tube (mm) | 430 | 465 | 500 | 535 | 555 | 585 |
| Head tube (mm) | 123 | 138 | 158 | 178 | 198 | 218 |
| Standover (mm) | 720 | 746 | 774 | 803 | 821 | 844 |
| Handling | ||||||
| Head angle (°) | 71 | 71.80 | 72.50 | 72.50 | 72.50 | 72.50 |
| Seat angle (°) | 74.80 | 74 | 73.50 | 73 | 73 | 72.50 |
| Chainstay (mm) | 412 | 412 | 412 | 412 | 412 | 412 |
| Wheelbase (mm) | 985 | 986 | 990 | 1,002 | 1,017 | 1,031 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 66.8 | 61.9 | 57.1 | 57.1 | 57.1 | 57.1 |
Frame Details
Frame Weight
Unknown
Frame Material
Aluminium
Forks
Full-composite OverDrive steerer
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105 2x12
Front Derailleur
Shimano 105 FD-R7000, braze-on type fitted with a band-on clamp adapter (Official)
Rear Derailleur
Shimano 105 GS
Cassette
Shimano 105 CS-R7000 (Official)
Cranks
Shimano 105 FC-R7000
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
cartridge
Chain
KMC X11EL-1 (Official / Regional variants note standard KMC X11)
Wheel & Tire Details
Wheelset Name
Shimano 105
Front Wheel Depth
25mm
Rear Wheel Depth
25mm
Tires
Giant Gavia Fondo 2, tubeless, 700x32c (34mm effective width)
Tire Type
Tubeless
Max Tire Size: 38 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105
Brake Rotors
160 mm front and 160 mm rear. Rotors are typically Shimano SM-RT70 Centerlock or model-year-specific Giant MPH patterns
Other Components
Saddle
Giant Approach
Seatpost
Giant D-Fuse, composite, 14mm offset
Handlebars
Giant D-Fuse SL
Bar Tape
Velo cork tape with gel
