Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano 105
Wheelset
Shimano 105
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Aluminium
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | M/L | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 157–169 cm | 165–175 cm | 171–181 cm | 177–187 cm | 183–193 cm | 189–199 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | — | 541 | 563 | 577 | 596 | 615 |
| Reach (mm) | — | 373 | 378 | 384 | 388 | 398 |
| Effective top tube (mm) | 515 | 530 | 545 | 560 | 575 | 595 |
| Seat tube (mm) | 410 | 445 | 480 | 515 | 535 | 565 |
| Head tube (mm) | 123 | 138 | 158 | 178 | 198 | 218 |
| Standover (mm) | 716 | 746 | 774 | 803 | 821 | 844 |
| Handling | ||||||
| Head angle (°) | 71 | 71.80 | 72.50 | 72.50 | 72.50 | 72.50 |
| Seat angle (°) | 74.80 | 74 | 73.50 | 73 | 73 | 72.50 |
| Chainstay (mm) | 412 | 412 | 412 | 412 | 412 | 412 |
| Wheelbase (mm) | 985 | 990 | 997 | 1,002 | 1,018 | 1,033 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 69.3 | 63.3 | 58.4 | 58.4 | 58.4 | 58.4 |
Frame Details
Frame Weight
Unknown
Frame Material
Aluminium
Forks
Advanced-grade composite, full-composite OverDrive steerer, disc
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105 2x12
Front Derailleur
Shimano 105 FD-R7000, braze-on format (Official)
Rear Derailleur
Shimano 105 GS
Cassette
Shimano 105 CS-HG700-11 (Official)
Cranks
Shimano FC-RS510
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano, press fit
Chain
KMC X11EL-1 (Official)
Wheel & Tire Details
Wheelset Name
Shimano 105
Front Wheel Depth
25mm
Rear Wheel Depth
25mm
Tires
Giant Gavia Fondo 2, tubeless, 700x28c (30mm efective width)
Tire Type
Tubeless
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105 hydraulic
Brake Rotors
160 mm front rotor / 140 mm rear rotor. Uses Giant MPH disc rotors
Other Components
Saddle
Giant Approach
Seatpost
Giant D-Fuse, composite, 14mm offset
Handlebars
Giant Connect
Bar Tape
Velo cork tape with gel
