Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Gravel
The style of riding intended for this bike
Bike Spec
Weight: 9.73 kg
The website average for Gravel bikes is 9.44 kg. This bike is 0.28 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano GRX-RX400
Wheelset
Giant P-X2 Disc wheelset
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 45 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
XS S M M/L L XLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | ML | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 556 | 570 | 586 | 602 | 616 | 630 |
| Reach (mm) | 381 | 381 | 387 | 391 | 397 | 407 |
| Effective top tube (mm) | 540 | 550 | 560 | 575 | 585 | 600 |
| Seat tube (mm) | 430 | 450 | 470 | 490 | 510 | 530 |
| Head tube (mm) | 125 | 135 | 150 | 165 | 180 | 195 |
| Standover (mm) | 724 | 740 | 757 | 774 | 791 | 807 |
| Handling | ||||||
| Head angle (°) | 70 | 71 | 71.50 | 72 | 72 | 72 |
| Seat angle (°) | 74 | 73.50 | 73.50 | 73 | 73 | 73 |
| Chainstay (mm) | 425 | 425 | 425 | 425 | 425 | 425 |
| Wheelbase (mm) | 1,024 | 1,020 | 1,026 | 1,031 | 1,041 | 1,056 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 78 | 72 | 68 | 65 | 65 | 65 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Giant Advanced-Grade Composite
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: 6-Bolt
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano GRX-RX400
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano GRX RX-400, 2x10
Front Derailleur
None
Rear Derailleur
Shimano GRX-RX400
Cassette
Shimano CS-LG400, 11-50T
Cranks
Shimano FC-U6030-1 (170mm to 175mm by size)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
FSA BB-AL86, press fit
Chain
KMC X11.
Wheel & Tire Details
Wheelset Name
Giant P-X2 Disc wheelset, alloy
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
Giant Crosscut Grip TR, 700x40c, tubeless
Tire Type
Tubeless
Max Tire Size: 45 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: 6-Bolt
How these disc brakes are mounted
Brakes
Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Rotors
160 mm front and 160 mm rear using Giant MPH disc rotors
Other Components
Saddle
Giant Grit
Seatpost
Giant D-Fuse, composite, 14mm offsetType: Rigid
Handlebars
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Bar Tape
Stratus Lite 3.0
