Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.36 kg
The website average for Road bikes is 8.56 kg. This bike is 1.20 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM RED eTap AXS
Wheelset
Bontrager Aeolus RSL
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 28 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
47 50 52 54 56 58 60 62This frame comes in 8 sizes, this is 2.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 47 cm | 50 cm | 52 cm | 54 cm | 56 cm | 58 cm | 60 cm | 62 cm |
|---|---|---|---|---|---|---|---|---|
| Frame geometry | ||||||||
| Stack (mm) | 507 | 521 | 533 | 541 | 563 | 581 | 601 | 620 |
| Reach (mm) | 373 | 378 | 383 | 386 | 391 | 396 | 399 | 403 |
| Effective top tube (mm) | 512 | 521 | 534 | 543 | 559 | 574 | 586 | 598 |
| Seat tube (mm) | 424 | 453 | 482 | 496 | 525 | 541 | 568 | 593 |
| Head tube (mm) | 100 | 111 | 121 | 131 | 151 | 171 | 191 | 210 |
| Standover (mm) | 719 | 743 | 768 | 781 | 805 | 821 | 844 | 866 |
| Handling | ||||||||
| Head angle (°) | 72.10 | 72.10 | 72.80 | 73 | 73.50 | 73.80 | 73.90 | 73.90 |
| Seat angle (°) | 74.60 | 74.60 | 74.20 | 73.70 | 73.30 | 73 | 72.80 | 72.50 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 | 410 | 412 |
| Wheelbase (mm) | 974 | 983 | 985 | 981 | 983 | 992 | 1,001 | 1,010 |
Frame Details
Frame Weight
This frame weighs 1050g
Frame Material
Carbon Fiber
Forks
Madone KVF full carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
SRAM RED eTap AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM RED eTap AXS, 12-speed
Front Derailleur
SRAM RED eTap AXS, braze-on type, electronic wireless (Official)
Rear Derailleur
SRAM RED eTap AXS, 36T max cog
Cassette
SRAM RED XG-1290, 12-speed (Official)
Cranks
SRAM RED DUB Carbon
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB, T47 threaded, internal bearing
Chain
SRAM RED, 12-speed with Flattop geometry (Official)
Battery
SRAM eTap battery pack (with charger)
Wheel & Tire Details
Wheelset Name
Bontrager Aeolus RSL
Front Wheel Depth
51mm
Rear Wheel Depth
51mm
Tires
Bontrager R4 320, 700x25 mm / Pirelli P Zero Race, 127 tpi, 700x26 mm
Tire Type
Clincher
Max Tire Size: 28 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Red AXS hydraulic disc
Brake Rotors
160 mm front and 160 mm rear [Official]
Other Components
Saddle
Aeolus RSL, carbon rails, 155 mm width
Seatpost
Madone aero carbon seat post, 0 mm offset, short length
Handlebars
Madone Integrated handlebar/stem
Bar Tape
Bontrager Supertack Perf tape
