Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight
The weight of this bike is unknown
Groupset
CAMPAGNOLO Super Record
Wheelset
Campagnolo Hyperon Ultra
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: No
You can't use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 155–163 cm | 163–170 cm | 170–175 cm | 175–180 cm | 180–188 cm | 188–196 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 514 | 527 | 544 | 565 | 591 | 612 |
| Reach (mm) | 375 | 380 | 384 | 395 | 402 | 408 |
| Effective top tube (mm) | 508 | 531 | 540 | 562 | 577 | 595 |
| Seat tube (mm) | 431 | 458 | 481 | 504 | 527 | 567 |
| Head tube (mm) | 109 | 120 | 137 | 157 | 184 | 204 |
| Standover (mm) | 705 | 730 | 753 | 776 | 801 | 824 |
| Handling | ||||||
| Head angle (°) | 71.75 | 72.50 | 73 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 75.50 | 74 | 74 | 73.50 | 73.50 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 412 |
| Wheelbase (mm) | 973 | 975 | 978 | 991 | 1,006 | 1,020 |
| Fork offset (mm) | 47 | 47 | 44 | 44 | 44 | 44 |
| Trail (mm) | 63 | 58 | 58 | 55 | 55 | 52 |
Frame Details
Frame Weight
This frame weighs 585g
Frame Material
Carbon Fiber
Forks
S-Works FACT Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
CAMPAGNOLO Super Record
Electric Groupset: Yes
This bike has electric gears
Shifters
CAMPAGNOLO Super Record
Front Derailleur
Campagnolo Super Record Wireless, Braze-on.
Rear Derailleur
CAMPAGNOLO Super Record, 12-speed
Cassette
Campagnolo Super Record 12-speed.
Cranks
Campagnolo Super Record Carbon Ultra-Torque
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
CAMPAGNOLO, Threaded
Chain
Campagnolo Super Record 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
CAMPAGNOLO Hyperon Ultra
Front Wheel Depth
37mm
Rear Wheel Depth
37mm
Tires
S-works Turbo 2BR, 700x28mm
Tire Type
Tubeless
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
CAMPAGNOLO Super Record, Hydraulic Disc
Brake Rotors
160mm Front / 140mm Rear
Other Components
Saddle
Body Geometry S-Works Power
Seatpost
Roval Alpinist Carbon Seatpost
Handlebars
S-Works Short & Shallow
Bar Tape
Supacaz Super Sticky Kush
