Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.2 kg
The website average for Road bikes is 8.56 kg. This bike is 0.36 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano Ultegra Di2
Wheelset
Reynolds ATR DB
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XXS XS S M L XLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 150–160 cm | 160–170 cm | 165–177 cm | 173–185 cm | 181–192 cm | 189–199 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 533 | 552 | 571 | 590 | 609 | 629 |
| Reach (mm) | 366 | 371 | 375 | 380 | 385 | 390 |
| Effective top tube (mm) | 511 | 524 | 540 | 557 | 574 | 592 |
| Seat tube (mm) | 440 | 470 | 500 | 530 | 560 | 590 |
| Head tube (mm) | 114 | 134 | 154 | 174 | 194 | 215 |
| Standover (mm) | 719 | 747 | 775 | 802 | 829 | 856 |
| Handling | ||||||
| Head angle (°) | 70.50 | 71 | 71.50 | 72 | 72.50 | 72.50 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73.50 | 73 | 73 |
| Chainstay (mm) | 418 | 418 | 418 | 418 | 418 | 418 |
| Wheelbase (mm) | 993 | 1,002 | 1,010 | 1,023 | 1,031 | 1,050 |
| Fork offset (mm) | 49 | 49 | 49 | 49 | 49 | 49 |
Frame Details
Frame Weight
This frame weighs 1124g
Frame Material
Carbon Fiber
Forks
SCULTURA ENDURANCE CF3 II, material: carbon, 700x35C max./ 700x32C (with fender) max. wheelsize, 100x12/ 142x12mm axle standard, BB86 bottom bracket standard
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano Ultegra Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Ultegra disc Di2
Front Derailleur
Shimano Ultegra Di2 FD-R8150.
Rear Derailleur
Shimano Ultegra Di2
Cassette
Shimano Ultegra CS-R8101.
Cranks
Shimano Ultegra FC-R8100
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano SM-BB72-41B, Pressfit 86.5
Chain
Shimano CN-M8100-12 (Ultegra/XT level 12-speed).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Reynolds ATR DB, 100x12mm width front hub, 142x12mm width rear hub, 23mm inner width, 40mm height, Centerlock, Shimano HG, material: carbon, Tubeless ready (tubeless tape and valves included)
Front Wheel Depth
41mm
Rear Wheel Depth
41mm
Tires
Front: Continental GP5000 AllSeason TR, 700x32C, fold, Rear: Continental GP5000 AllSeason TR, 700x32C, fold
Tire Type
Tubeless
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano Ultegra, Hydraulic disc
Brake Rotors
160 mm front and 160 mm rear Centerlock rotors (Shimano RT-CL800 series)
Other Components
Saddle
Prologo Scratch M5, V-mount adapter, incl. MERIDA minitool
Seatpost
Shimano CL800 160mm
Handlebars
MERIDA TEAM SL 1P INTEGRATED, material: carbon, 380mm (XXS-XS-S), 400mm (M-L), 420mm (XL)
Bar Tape
MERIDA ROAD Expert
