Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.8 kg
The website average for Road bikes is 8.56 kg. This bike is 0.23 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Rival AXS
Wheelset
Fulcrum Racing 900 DB
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider height | — | 164–173 cm | 171–180 cm | 178–187 cm | 185+ cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 536 | 557 | 582 | 606 | 631 |
| Reach (mm) | 366 | 373 | 379 | 385 | 392 |
| Effective top tube (mm) | 516 | 530 | 545.5 | 562 | 580 |
| Seat tube (mm) | 460 | 485 | 510 | 535 | 560 |
| Head tube (mm) | 117 | 142 | 170 | 196 | 224 |
| Standover (mm) | 743 | 766 | 790 | 813 | 837 |
| Handling | |||||
| Head angle (°) | 70.30 | 70.50 | 70.80 | 71.30 | 71.50 |
| Seat angle (°) | 74.50 | 74.20 | 74 | 73.50 | 73 |
| Chainstay (mm) | 415 | 415 | 415 | 415 | 415 |
| Wheelbase (mm) | 997.5 | 1,006.3 | 1,016.3 | 1,024.5 | 1,037.2 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 69.2 | 67.9 | 65.8 | 62.5 | 61.2 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Look Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Rival AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM RIVAL ETAP AXS Wireless Hydraulic
Front Derailleur
SRAM Rival eTap AXS.
Rear Derailleur
SRAM RIVAL ETAP AXS Wireless
Cassette
SRAM XG-1250 10-36T 12-Speed
Cranks
SRAM Rival DUB (170mm to 175mm)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
BB T 47 85.5 SRAM DUB
Chain
SRAM Rival 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
FULCRUM RACING 900 DB 2WF C19 Black Decals
Front Wheel Depth
22.5mm
Rear Wheel Depth
22.5mm
Tires
HUTCHINSON FUSION 5 Tubeless Ready 700 X 30
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Hydraulic Disc
Brake Rotors
160 mm front / 140 mm rear utilizing the Centerlock mounting standard
Other Components
Saddle
LOOK by S MARCO Short Fit Dynamic Open Fit
Seatpost
LOOK LS3 Alloy 27.2 mm 350 mm
Handlebars
LOOK LS2 Alloy (XS –S 40 / M – L 42 / XL 44) )
