Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.4 kg
The website average for Road bikes is 8.56 kg. This bike is 0.16 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival eTap AXS
Wheelset
Vision SC55 Disc
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
3XS XXS XS S M L XLThis frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 3XS | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | 150–157 cm | 155–163 cm | 160–168 cm | 167–175 cm | 173–182 cm | 181–190 cm | 188–198 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 512 | 517 | 529 | 542 | 557 | 571 | 593 |
| Reach (mm) | 373 | 377 | 384 | 390 | 395 | 400 | 409 |
| Effective top tube (mm) | 520 | 525 | 535 | 545 | 560 | 575 | 590 |
| Seat tube (mm) | 470 | 470 | 500 | 520 | 540 | 560 | 590 |
| Head tube (mm) | 97 | 102 | 112 | 128 | 140 | 155 | 175 |
| Standover (mm) | 745 | 751 | 771 | 792 | 810 | 826 | 853 |
| Handling | |||||||
| Head angle (°) | 71 | 71.50 | 72 | 72.50 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 74.50 | 74.50 | 74 | 74 | 73.50 | 73 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 981 | 987 | 984 | 992 | 992 | 1,002 | 1,011 |
Frame Details
Frame Weight
This frame weighs 1185g
Frame Material
Carbon Fiber
Forks
REACTO CF3 IV, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, BB86,5 bottom bracket standard
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival eTap AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTAP AXS HRD
Front Derailleur
SRAM Rival eTap AXS
Rear Derailleur
SRAM Rival eTap AXS, SS
Cassette
SRAM XG-1250 D1
Cranks
SRAM Rival AXS
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
BB86/BB92, 86mm, press-fit
Chain
SRAM Rival 12-speed (Flattop profile system) (Inferred from standard groupset family matching).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Vision SC55 Disc brake, 100x12mm width front hub, 142x12mm width rear hub, 19mm inner width, 55mm height, Centerlock, material: carbon
Front Wheel Depth
55mm
Rear Wheel Depth
55mm
Tires
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM ED Rival eTap AXS, Hydraulic disc
Brake Rotors
160 mm front / 160 mm rear (SRAM Paceline or CenterLine Centerlock standard). Front and rear calipers feature Merida's integrated CNC-machined aluminium Disc Cooler fins fixed behind the mount positions to mitigate brake fade
Other Components
Saddle
MERIDA EXPERT SL, 6% recycled and 23% nature material, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM CW Aero shape 15mm setback Carbon
Handlebars
Vision Metron Aero Bar, material: carbon, 380mm (3XS-XXS-XS-S), 400mm (M-L-XL)
