Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Shimano GRX RX610
Wheelset
Alloy Tubeless 700c
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 50 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
XS S M L XL XXLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 650b | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 535 | 557 | 578 | 599 | 621 | 640 |
| Reach (mm) | 386 | 390 | 395 | 400 | 405 | 410 |
| Effective top tube (mm) | 535 | 547 | 561 | 573 | 585 | 596 |
| Seat tube (mm) | 410 | 440 | 470 | 505 | 540 | 575 |
| Head tube (mm) | 110 | 132.5 | 153.5 | 175 | 198 | 218 |
| Standover (mm) | 690 | 720 | 749 | 780 | 811 | 842 |
| Handling | ||||||
| Head angle (°) | 69 | 69.50 | 70 | 70.50 | 70.80 | 71 |
| Seat angle (°) | 74 | 74 | 73.50 | 73.50 | 73 | 73 |
| Chainstay (mm) | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase (mm) | 1,031 | 1,041 | 1,052 | 1,061 | 1,072 | 1,081 |
| BB drop (mm) | 80 | 80 | 80 | 80 | 80 | 80 |
Frame Details
Frame Weight
This frame weighs 1040g
Frame Material
Carbon Fiber
Forks
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano GRX RX610
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano GRX RX610
Front Derailleur
None
Rear Derailleur
Shimano GRX RX822 GS
Cassette
Shimano CS-M7100-12 (SLX tier) or Shimano HG710
Cranks
Shimano GRX RX610 (170mm to 175mm)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
PF30, press-fit
Chain
Shimano M6100 (Deore tier 12-speed)
Wheel & Tire Details
Wheelset Name
Alloy, Tubeless, 700c, 21c
Front Wheel Depth
22mm
Rear Wheel Depth
22mm
Tires
Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Tire Type
Clincher
Max Tire Size: 50 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano RX400 Hydraulic disc
Brake Rotors
160mm front and 160mm rear Shimano Center Lock brake rotors
Other Components
Saddle
Prologo Akero AGX black rails size 155mm
Seatpost
Handlebars
OC Gravel GR31, Reach 70, Drop 110
Bar Tape
Orbea Anti-Slippery/Shock Proof
