Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.1 kg
The website average for Road bikes is 8.56 kg. This bike is 0.46 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival eTap AXS
Wheelset
Vision SC30 DB
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 30 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
3XS XXS XS S M L XLThis frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 517 | 529 | 542 | 557 | 571 | 593 |
| Reach (mm) | 377 | 383 | 390 | 395 | 400 | 409 |
| Effective top tube (mm) | 520 | 535 | 545 | 560 | 575 | 590 |
| Seat tube (mm) | 445 | 470 | 490 | 501 | 520 | 540 |
| Head tube (mm) | 104 | 115 | 127 | 140 | 155 | 178 |
| Standover (mm) | 724 | 746 | 765 | 777 | 796 | 815 |
| Handling | ||||||
| Head angle (°) | 71.30 | 72 | 72.80 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 74.50 | 74 | 74 | 73.50 | 73 | 73 |
| Chainstay (mm) | 408 | 408 | 408 | 408 | 408 | 408 |
| Wheelbase (mm) | 983 | 988 | 989 | 990 | 1,001 | 1,011 |
| Fork offset (mm) | 45 | 45 | 45 | 45 | 45 | 45 |
Frame Details
Frame Weight
This frame weighs 997g
Frame Material
Carbon Fiber
Forks
SCULTURA CF3 V, material: carbon, 700x30C max. wheelsize, 100x12/ 142x12mm axle standard, Pressfit 86,5
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival eTap AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTAP AXS HRD
Front Derailleur
SRAM Rival AXS E1 braze-on.
Rear Derailleur
SRAM Rival eTap AXS, SS
Cassette
SRAM XG-1250 D1.
Cranks
SRAM Rival AXS with Quarq technology spindle power meter
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
BB86/BB92, 86mm, press-fit
Chain
SRAM Rival E1 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Vision SC30 DB, 100x12mm width front hub, 142x12mm width rear hub, 19mm inner width, 30mm height, Centerlock, material: carbon
Front Wheel Depth
45mm
Rear Wheel Depth
45mm
Tires
Continental Grand Prix 5000S TR, 700x28C, fold, tubeless ready
Tire Type
Clincher
Max Tire Size: 30 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Rival eTap AXS, Hydraulic disc
Brake Rotors
SRAM Paceline RT-PLN-A2 Centerlock configuration | 160 mm front and 160 mm rear standard
Other Components
Saddle
MERIDA EXPERT SL, 6% recycled and 23% nature material, V-mount, incl. MERIDA minitool
Seatpost
MERIDA TEAM SL 27.2mm diameter 15mm setback Carbon S-Flex
Handlebars
SL-K Compact, material: carbon, 380mm (3XS-XXS-XS), 400mm (S-M-L-XL)
