Bike Info
Worldwide Shipping: No
Only delivered to specific countries
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.2 kg
The website average for Road bikes is 8.56 kg. This bike is 1.36 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano Ultegra 6810
Wheelset
Ksyrium Elite S
Brake Type: Rim Brake
That old school attraction!
Frameset Material
Carbon Fiber
Max Tire Size: 25 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | Size XS |
|---|---|
| Sizing | |
| Wheel size | 700c |
| Frame geometry | |
| Effective top tube (mm) | 530 |
Frame Details
Frame Weight
This frame weighs 850g
Frame Material
Carbon Fiber
Forks
Carbon Fiber fork
Fork Material
The forks are made from Carbon Fiber
Cables: Externally Routed
Routed outside the bars, stem and frame
Axel Type: QR Skewer
How the wheels are secured to the frame
Brake Type: Rim Brake
That old school attraction!
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano Ultegra 6810
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano Ultegra
Front Derailleur
Shimano Ultegra FD-6800 (Braze-on) (Inferred from groupset family).
Rear Derailleur
Shimano Ultegra 6800
Cassette
Shimano Ultegra CS-6800 (Inferred from groupset family).
Cranks
Shimano Ultegra FC-6800
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
PressFit 86
Chain
Shimano Ultegra HG701 (or matching KMC 11-speed chain variant natively paired by the retailer).
Wheel & Tire Details
Wheelset Name
Ksyrium Elite S
Front Wheel Depth
22mm
Rear Wheel Depth
25mm
Tires
Yksion Pro GripLink
Tire Type
Clincher
Max Tire Size: 25 mm
This is the max tire size you can use
Brakes
Brake Type: Rim Brake
That old school attraction!
Brakes
Front calliper: Shimano Ultegra 6810 Direct Mount, 2 symmetrical axles for more efficient braking control and greater braking power. Adjustable spring tension. Rear calliper: Shimano Ultegra 6810 (classic mounting on seat stay).
Brake Rotors
Unknown
Other Components
Saddle
Fizik Antares R7 P
Seatpost
Handlebars
Compact Deda Zero 2 handlebar
