Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Gravel
The style of riding intended for this bike
Bike Spec
Weight: 9.7 kg
The website average for Gravel bikes is 9.44 kg. This bike is 0.25 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano GRX
Wheelset
DT Swiss GR1600
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 53 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider height | 152–160 cm | 161–170 cm | 169–178 cm | 177–187 cm | 186–195 cm |
| Frame geometry | |||||
| Stack (mm) | 546 | 557 | 576 | 595 | 623 |
| Reach (mm) | 375 | 390 | 395 | 405 | 420 |
| Effective top tube (mm) | 512 | 535 | 553 | 571 | 598 |
| Seat tube (mm) | 430 | 450 | 480 | 510 | 540 |
| Head tube (mm) | 100 | 110 | 130 | 150 | 180 |
| Standover (mm) | 761 | 789 | 805 | 832 | 857 |
| Handling | |||||
| Head angle (°) | 70.50 | 71 | 71 | 71.50 | 71.50 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73.50 | 73 |
| Chainstay (mm) | 425 | 425 | 425 | 425 | 425 |
| Wheelbase (mm) | 1,016 | 1,030 | 1,041 | 1,058 | 1,083 |
| Fork offset (mm) | 53 | 53 | 53 | 53 | 53 |
| BB drop (mm) | 75 | 75 | 75 | 75 | 75 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Full Carbon / Suspension-Fork Compatible
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano GRX
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano GRX ST-RX820, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano GRX RD-RX820, 12-speed
Cassette
SRAM XS-1270, 10-52T
Cranks
SRAM Apex D1 Wide (Size-specific: 165mm to 175mm)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Pressfit Road BB86
Chain
SRAM Eagle 70
Wheel & Tire Details
Wheelset Name
DT Swiss GR1600, 25 mm height
Front Wheel Depth
20mm
Rear Wheel Depth
20mm
Tires
WTB Riddler, 700 x 45C, folding | WTB Riddler, 700 x 45C, folding
Tire Type
Clincher
Max Tire Size: 53 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano GRX BL-RX810, 11-speed | Shimano GRX BL-RX810, 11-speed
Brake Rotors
SRAM Centerline centrelock disc rotors. The configuration utilizes size-specific diameter parameters at the front end:
Other Components
Saddle
Prologo Akero
Seatpost
Lee Chi SP-926, Carbon Fiber, 27,2mm, set-back: 0mm
Handlebars
Easton EA70 AX, 31.8 mm, drop: 125 mm, reach: 80 mm, flair: 16°
Bar Tape
FOCUS Bartape SL
