Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 6.3 kg
The website average for Road bikes is 8.56 kg. This bike is 2.27 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Red eTap
Wheelset
Roval Alpinist CLX
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: No
You can't use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 155–163 cm | 163–170 cm | 170–175 cm | 175–180 cm | 180–188 cm | 188–196 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 514 | 527 | 544 | 565 | 591 | 612 |
| Reach (mm) | 375 | 380 | 384 | 395 | 402 | 408 |
| Effective top tube (mm) | 508 | 531 | 540 | 562 | 577 | 595 |
| Seat tube (mm) | 431 | 462 | 481 | 504 | 532 | 567 |
| Head tube (mm) | 109 | 120 | 137 | 157 | 184 | 204 |
| Standover (mm) | 705 | 728 | 748 | 769 | 796 | 824 |
| Handling | ||||||
| Head angle (°) | 71.75 | 72.50 | 73 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 75.50 | 74 | 74 | 73.50 | 73.50 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 973 | 975 | 978 | 991 | 1,005 | 1,012 |
| Fork offset (mm) | 47 | 47 | 44 | 44 | 44 | 44 |
| Trail (mm) | 63 | 58 | 58 | 55 | 55 | 52 |
Frame Details
Frame Weight
This frame weighs 585g
Frame Material
Carbon Fiber
Forks
S-Works FACT Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Red eTap
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Red eTap AXS
Front Derailleur
SRAM RED eTap AXS, braze-on fitment type.
Rear Derailleur
SRAM RED eTAP AXS, 12-speed
Cassette
SRAM RED XG-1290, 10-33t
Cranks
SRAM RED AXS Carbon (Size-scaled 165mm - 175mm)
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM RED 12-speed Flattop
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Roval Alpinist CLX
Front Wheel Depth
33mm
Rear Wheel Depth
33mm
Tires
S-works Turbo 2BR, 700x28mm
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Red eTAP AXS, hydraulic disc
Brake Rotors
160 mm front / 160 mm rear Center Lock standard disc brakes
Other Components
Saddle
Body Geometry S-Works Power
Seatpost
Roval Alpinist Carbon Seatpost
Handlebars
S-Works Short & Shallow
Bar Tape
Supacaz Super Sticky Kush
