eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2023
The bike was released 3 years ago
Screen
Bosch Intuvia 100 + LED Remote
Lights Included
No
Weight (inc battery): 24.5 kg
The website average for electric bikes is 22.99 kg. This electric bike is 1.50 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
XS: <167 cm, SM: 165–175 cm, MD: 173–184 cm, LG: 182–192 cm, XL: 190+ cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Yak 25 double-wall aluminium rims laced to Haibike The Hub++ 6-bolt disc hubs with black Sapim Leader spokes
Wheelset Size
27.5 inch
Tires
WTB, Groov-E, 62-584, 27.5" x 2.4"
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
130 kg (286.6 lbs)
Drivechain Details
Groupset details
Alivio
Drivechain type
Chain drive
Shifters
Shimano Alivio M 3100 Rapidfire trigger shifter
Amount of gears
11 Gears
Rear Derailleur
Shimano Alivio M 3100 SGS
Front Derailleur
None
Cassette
Shimano HG 200, 9-speed with an 11-36 teeth gear spread
Cranks
Miranda No.7 steel crank arms fitted with a 38-teeth steel chainring
Chain
KMC e 9 S
Bottom Bracket
None (The bottom bracket mechanism is completely integrated directly inside the casing of the Bosch mid-drive motor system)
Brakes
Brakes
Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
180 mm front and rear
Shifters
Shimano Alivio M 3100 Rapidfire trigger shifter
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
