eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2023
The bike was released 3 years ago
Screen
Intuvia 100
Lights Included
No
Weight (inc battery): 27 kg
The website average for electric bikes is 22.99 kg. This electric bike is 4.00 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
S: 160–170 cm, M: 168–178 cm, L: 175–185 cm, XL: 183–195 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Jak 25 double-wall aluminium eyeleted rims bound to Alu Naben disc hubs
Wheelset Size
27.5 inch
Tires
WTB, Groov-E, 62-584, 27.5" x 2.4"
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
130 kg (286.6 lbs)
Drivechain Details
Groupset details
Alivio
Drivechain type
Chain drive
Shifters
Shimano Alivio M 3100 Rapidfire trigger mechanism
Amount of gears
11 Gears
Rear Derailleur
Shimano Alivio M 3100 SGS
Front Derailleur
None
Cassette
Shimano HG 200 11-36 T
Cranks
Haibike forged aluminium crank arms paired with a 38 T steel chainring
Chain
KMC e 9 S
Bottom Bracket
Integrated inside the motor assembly (the crankshaft spins directly on internal Bosch drive bearings)
Brakes
Brakes
hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
180 mm front / 180 mm rear
Shifters
Shimano Alivio M 3100 Rapidfire trigger mechanism
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
