eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2024
The bike was released 2 years ago
Screen
Yamaha Multi Switch / 1.7" LCD
Lights Included
No
Weight (inc battery): 24.5 kg
The website average for electric bikes is 22.99 kg. This electric bike is 1.50 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
S: 160–170 cm, M: 168–178 cm, L: 175–185 cm, XL: 183–195 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Yak 25 double-walled aluminium rims with eyelets, laced with Sapim Leader spokes over aluminium hubs
Wheelset Size
27.5 inch
Tires
Schwalbe Al Grounder Performance 60-584
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
130 kg (286.6 lbs)
Drivechain Details
Groupset details
Deore
Drivechain type
Chain drive
Shifters
Shimano Deore M 4100, trigger switch setup
Amount of gears
10 Gears
Rear Derailleur
Shimano Deore M 4120
Front Derailleur
None
Cassette
Shimano CSM 4100 (or HG 41 depending on precise sub-batch assembly), 11-42 teeth range
Cranks
Haibike Forged Aluminium crank arms with a 38 T steel chainring
Chain
KMC e 10 S e-bike optimized chain
Bottom Bracket
Integrated directly into the sealed Yamaha PW-ST motor housing
Brakes
Brakes
Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
Alhonga DXR 1806 180 mm rotors front and rear
Shifters
Shimano Deore M 4100, trigger switch setup
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
