eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2023
The bike was released 3 years ago
Screen
Yamaha Side Switch, 1.7" LCD
Lights Included
No
Weight (inc battery): 25.4 kg
The website average for electric bikes is 22.99 kg. This electric bike is 2.40 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
SM, MD, LG, XL and XXL
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Yak 25 alloy double-wall rims laced via Sapim Leader black spokes to Shimano MT 400-B (front) and MT 410 (rear) Centerlock thru-axle hubs
Wheelset Size
27.5 inch
Tires
Schwalbe, Johnny Watts, 60-584, 27.5" x 2.35"
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
150 kg (330.7 lbs)
Drivechain Details
Groupset details
GX Eagle, SX Eagle
Drivechain type
Chain drive
Shifters
SRAM SX Eagle, trigger switch
Amount of gears
12 Gears
Rear Derailleur
SRAM GX Eagle
Front Derailleur
None
Cassette
SRAM Eagle PG 1210 (11-50 Teeth, 12-speed)
Cranks
Haibike Components The Cranks ++ (Aluminium)
Chain
SRAM SX Eagle
Bottom Bracket
Integrated into the Yamaha PW-X 3 motor unit (splined interface)
Brakes
Brakes
Shimano hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
Shimano RT 30 (203 mm front / 180 mm rear)
Shifters
SRAM SX Eagle, trigger switch
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
