Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.8 kg
The website average for Road bikes is 8.56 kg. This bike is 0.23 kg over the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival eTap AXS
Wheelset
SRAM Rival eTap AXS
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M M/L L XLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | ML | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 157–169 cm | 165–175 cm | 171–181 cm | 177–187 cm | 183–193 cm | 189–199 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 522 | 546 | 567 | 586 | 605 | 624 |
| Reach (mm) | 370 | 374 | 377 | 381 | 390 | 398 |
| Effective top tube (mm) | 515 | 530 | 545 | 560 | 575 | 595 |
| Seat tube (mm) | 410 | 445 | 480 | 515 | 535 | 565 |
| Head tube (mm) | 120 | 140 | 160 | 185 | 205 | 225 |
| Standover (mm) | 731 | 756 | 786 | 816 | 835 | 861 |
| Handling | ||||||
| Head angle (°) | 70.50 | 71.80 | 72.50 | 72.50 | 72.50 | 72.50 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73 | 73 | 72.50 |
| Chainstay (mm) | 420 | 420 | 420 | 420 | 420 | 420 |
| Wheelbase (mm) | 995 | 995 | 998 | 1,010 | 1,025 | 1,040 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 71.2 | 63.1 | 58.2 | 58.2 | 58.2 | 58.2 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Advanced-grade composite, full-composite steerer, disc
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: 6-Bolt
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival eTap AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTap AXS
Front Derailleur
SRAM Rival eTap AXS, braze-on.
Rear Derailleur
SRAM Rival eTap AXS
Cassette
SRAM Rival, 12-speed.
Cranks
SRAM Rival D1 DUB
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM Rival D1, 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
SRAM Rival eTap AXS
Front Wheel Depth
24mm
Rear Wheel Depth
24mm
Tires
Giant Gavia Fondo 1, tubeless, 700x32c (33.5mm), folding
Tire Type
Tubeless
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: 6-Bolt
How these disc brakes are mounted
Brakes
SRAM Rival eTap AXS hydraulic
Brake Rotors
Dual-diameter profile setup featuring a 160mm front rotor and a 140mm rear rotor
Other Components
Saddle
Giant Approach
Seatpost
Giant D-Fuse, composite, 14mm offset
Handlebars
Giant Contact SL D-Fuse S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
Bar Tape
Stratus Lite 3.0
