Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Sram Rival XPLR AXS 13s
Wheelset
Oquo Road Control RC25 Pro
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 50 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XL XXLThis frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 155–166 cm | 167–172 cm | 173–179 cm | 180–185 cm | 186–191 cm | 192–207 cm |
| Wheel size | 700c | 650b | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 535 | 556 | 573 | 592 | 613 | 632 |
| Reach (mm) | 386 | 391 | 393 | 395 | 402 | 404 |
| Effective top tube (mm) | 530 | 542 | 555 | 570 | 587 | 600 |
| Seat tube (mm) | 405 | 438 | 471 | 504 | 524 | 554 |
| Head tube (mm) | 116 | 137 | 155 | 178 | 199 | 219 |
| Standover (mm) | 725 | 751 | 775 | 803 | 823 | 848 |
| Handling | ||||||
| Head angle (°) | 70 | 70.50 | 71 | 71 | 71.50 | 72 |
| Seat angle (°) | 74 | 74 | 73.50 | 73.50 | 73 | 73 |
| Chainstay (mm) | 430 | 430 | 430 | 430 | 430 | 430 |
| Wheelbase (mm) | 1,024 | 1,032 | 1,040 | 1,054 | 1,066 | 1,075 |
| Fork offset (mm) | 53 | 53 | 48 | 48 | 43 | 43 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
Orbea Terra carbon OMR Disc, monocoque construction, HS 1,5", PF30, powermeter compatible, Thru Axle 12x142mm rear, thread M12x2 P1, Internal Cable Routing, LOCKR service box
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Sram Rival XPLR AXS 13s
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTap AXS
Front Derailleur
None
Rear Derailleur
SRAM Rival XPLR eTAP AXS
Cassette
SRAM XG-1351 XPLR.
Cranks
SRAM Rival 1 XPLR DUB Wide (165mm to 175mm depending on size or MyO customization choices).
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
PF30, press-fit
Chain
SRAM Rival 12/13-speed Flattop chain.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Oquo Road Control RC25PRO
Front Wheel Depth
25mm
Rear Wheel Depth
25mm
Tires
Vittoria Terreno Dry CX-Gravel G2.0 TNT 700x38c
Tire Type
Tubeless
Max Tire Size: 50 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Rival eTap AXS
Brake Rotors
160 mm Front / 160 mm Rear standard center-lock rotors
Other Components
Saddle
Prologo Akero AGX black rails size 155mm
Seatpost
Handlebars
OC Gravel GR31, Reach 70, Drop 110
Bar Tape
Orbea Anti-Slippery/Shock Proof
