Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 9.1 kg
The website average for Road bikes is 8.56 kg. This bike is 0.53 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Rival AXS
Wheelset
DT Swiss E1800
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: No
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Sizing | |||||
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 535 | 556 | 578 | 603 | 633 |
| Reach (mm) | 368 | 376 | 383 | 389 | 403 |
| Effective top tube (mm) | 511 | 530 | 549 | 568 | 597 |
| Seat tube (mm) | 455 | 485 | 505 | 535 | 575 |
| Head tube (mm) | 115 | 134 | 154 | 179 | 209 |
| Handling | |||||
| Chainstay (mm) | 415 | 415 | 415 | 415 | 415 |
| Wheelbase (mm) | 989 | 999 | 1,004 | 1,017 | 1,036 |
| BB drop (mm) | 75 | 75 | 75 | 75 | 75 |
Frame Details
Frame Weight
This frame weighs 1130g
Frame Material
Carbon Fiber
Forks
Paralane Carbon Fiber disc, integrated cable routing, disc, 100x12 mm, flat mount
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Rival AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTap AXS, 12-speed
Front Derailleur
SRAM Rival eTap AXS braze-on, 12-speed.
Rear Derailleur
SRAM Rival eTap AXS, 12-speed
Cassette
SRAM XG-1250 (Official specification sheets list the XG-1250, though select regional databases alternate with the cross-compatible XG-1251).
Cranks
SRAM Rival AXS
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM Rival AXS, 12-speed with Flattop design.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
DT Swiss E 1800, alloy, 30 mm height
Front Wheel Depth
30mm
Rear Wheel Depth
30mm
Tires
Vittoria Zaffiro Pro, 700 x 32C, Folding | Vittoria Zaffiro Pro, 700 x 32C, Folding
Tire Type
Clincher
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Rival eTap AXS, 12-speed | SRAM Rival eTap AXS, 12-speed
Brake Rotors
160 mm front and 160 mm rear standard stock. (Technical note: The frame's constructive structural capacity allows for a maximum native fitment up to an 180 mm rotor in the front)
Other Components
Saddle
Selle Royal Groove SRX
Seatpost
BBB FlyPost SP-135, 27,2mm, Carbon Fiber, set-back: 15 mm
Handlebars
BBB Basic, aluminium, drop: 125 mm, reach: 70 mm
Bar Tape
FOCUS Bartape SL
