Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Gravel
The style of riding intended for this bike
Bike Spec
Weight: 8.7 kg
The website average for Gravel bikes is 9.44 kg. This bike is 0.74 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Rival XPLR AXS, Rival AXS
Wheelset
DT Swiss GR1600
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 45 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XS | S | M | L | XL |
|---|---|---|---|---|---|
| Sizing | |||||
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 549 | 572 | 595 | 618 | 641 |
| Reach (mm) | 385 | 395 | 405 | 415 | 425 |
| Effective top tube (mm) | 536 | 557 | 577 | 598 | 619 |
| Seat tube (mm) | 460 | 490 | 520 | 550 | 580 |
| Head tube (mm) | 100 | 125 | 150 | 175 | 200 |
| Standover (mm) | 761 | 788 | 813 | 839 | 864 |
| Handling | |||||
| Head angle (°) | 70.50 | 70.50 | 70.50 | 70.50 | 70.50 |
| Seat angle (°) | 74 | 74 | 74 | 74 | 74 |
| Chainstay (mm) | 430 | 430 | 430 | 430 | 430 |
| Wheelbase (mm) | 1,033 | 1,056 | 1,077 | 1,099 | 1,121 |
| Fork offset (mm) | 50 | 50 | 50 | 50 | 50 |
| Trail (mm) | 76 | 76 | 76 | 76 | 76 |
Frame Details
Frame Weight
This frame weighs 995g
Frame Material
Carbon Fiber
Forks
Focus Carbon Technology Disc
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Rival XPLR AXS, Rival AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTap AXS, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM Rival eTap AXS XPLR, 12-speed
Cassette
SRAM XG-1351 XPLR.
Cranks
SRAM Rival E1 DUB
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM PF DUB 86
Chain
SRAM Rival E1 Flattop.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
DT Swiss GR1600, 25 mm height
Front Wheel Depth
54mm
Rear Wheel Depth
54mm
Tires
WTB Riddler, 700 x 45C, folding | WTB Riddler, 700 x 45C, folding
Tire Type
Tubeless
Max Tire Size: 45 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Rival AXS | SRAM Rival AXS
Brake Rotors
Equipped with SRAM HS2 disc rotors
Other Components
Saddle
Prologo Akero
Seatpost
Easton EC70, Carbon Fiber, 27.2 mm, set-back: 0 mm
Handlebars
FOCUS JD RA85 alloy, 31,8 mm, drop: 116 mm, reach: 74 mm, flare: 10°
Bar Tape
FOCUS Bartape SL
