Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
SRAM Force eTap AXS
Wheelset
Reserve 37TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 497 | 519 | 542 | 565 | 588 | 614 |
| Reach (mm) | 367 | 376 | 384 | 393 | 401 | 410 |
| Effective top tube (mm) | 515 | 531 | 548 | 564 | 581 | 598 |
| Seat tube (mm) | 422 | 453 | 483 | 514 | 544 | 575 |
| Head tube (mm) | 93 | 114 | 137 | 163 | 192 | 218 |
| Standover (mm) | 695 | 724 | 755 | 778 | 800 | 824 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73 | 73 | 73 |
| Seat angle (°) | 73 | 73 | 73 | 73 | 73 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 972 | 974 | 977 | 994 | 1,011 | 1,028 |
| Fork offset (mm) | 57.5 | 51.5 | 45.5 | 45.5 | 45.5 | 45.5 |
| Trail (mm) | 57.3 | 57.3 | 57.3 | 57.3 | 57.3 | 57.3 |
Frame Details
Frame Weight
This frame weighs 651g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Tapered R5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Force eTap AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Force AXS, 12 speed
Front Derailleur
SRAM Force AXS, 12-speed.
Rear Derailleur
SRAM Force AXS, 12 speed
Cassette
SRAM Force, 12-speed.
Cranks
SRAM Force AXS DUB
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB Ceramic, BBright
Chain
SRAM Force, 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Rear: Reserve 37TA, Zipp ZR1 SS, 12x142mm,Front: Reserve 34TA, Zipp ZR1 SS, 12x100mm
Front Wheel Depth
34mm
Rear Wheel Depth
37mm
Tires
Corsa Pro TLR 700x26mm
Tire Type
Tubeless
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Force
Brake Rotors
160mm front and 160mm rear (SRAM Paceline Centerlock rotors fitted stock)
Other Components
Saddle
Prologo Scratch M5 PAS TiRox
Seatpost
Cervélo SP24 Carbon
Handlebars
Cervélo HB13 Carbon, 31.8mm clamp
