Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
SRAM Force AXS
Wheelset
Reserve 42TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 36 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 152–163 cm | 163–170 cm | 170–178 cm | 178–185 cm | 185–193 cm | 193–200 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 505 | 530 | 555 | 580 | 605 | 630 |
| Reach (mm) | 360 | 369 | 378 | 387 | 396 | 405 |
| Effective top tube (mm) | 502 | 522 | 543 | 565 | 581 | 598 |
| Head tube (mm) | 89.5 | 110.3 | 136.3 | 162.6 | 191.5 | 217.8 |
| Standover (mm) | 701 | 743 | 775 | 798 | 824 | 847 |
| Handling | ||||||
| Head angle (°) | 70.50 | 71.50 | 72 | 72 | 72 | 72 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73 | 73 | 73 |
| Chainstay (mm) | 415 | 415 | 415 | 415 | 415 | 415 |
| Wheelbase (mm) | 983.3 | 985.6 | 996.3 | 1,013.4 | 1,031.8 | 1,048.9 |
| Fork offset (mm) | 60 | 54 | 51 | 51 | 51 | 51 |
| Trail (mm) | 57.8 | 57.8 | 57.8 | 57.8 | 57.8 | 57.8 |
| BB drop (mm) | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
Frame Details
Frame Weight
This frame weighs 995g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Tapered Caledonia-5 Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Force AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Force AXS E1
Front Derailleur
SRAM Force AXS, braze-on type.
Rear Derailleur
SRAM Force AXS E1
Cassette
SRAM Force, XG-1270, 12-speed.
Cranks
SRAM Force AXS DUB (170-175mm by size)
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB, BBright
Chain
SRAM Force, 12-speed, Flattop design.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
F:Reserve 42TA, DT Swiss 350, 12x100mm R: Reserve 49TA, DT Swiss 350, 12x142mm, XDR freehub,
Front Wheel Depth
42mm
Rear Wheel Depth
49mm
Tires
Vittoria Corsa N.EXT TLR G2.0 700x30c
Tire Type
Clincher
Max Tire Size: 36 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Force
Brake Rotors
160mm front and 160mm rear (Utilises SRAM Paceline Centerlock rotors as the default factory specification)
Other Components
Saddle
Selle Italia NOVUS BOOST EVO SuperFlow Ti
Seatpost
Cervélo SP24 Carbon
Handlebars
Cervélo HB13 Carbon, 31.8mm clamp
Bar Tape
Cervélo HB13 Carbon, 31.8mm clamp
