Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 9.5 kg
The website average for Road bikes is 8.56 kg. This bike is 0.93 kg over the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival ETAP AXS
Wheelset
Roval Terra C
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 47 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61 64This frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 49 | 52 | 54 | 56 | 58 | 61 | 64 |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | 152–163 cm | 163–170 cm | 170–178 cm | 175–183 cm | 180–188 cm | 188–196 cm | 196–205 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 571 | 592 | 610 | 610 | 632 | 654 | 674 |
| Reach (mm) | 365 | 374 | 383 | 392 | 401 | 410 | 419 |
| Effective top tube (mm) | 529 | 545 | 561 | 578 | 599 | 618 | 635 |
| Seat tube (mm) | 400 | 432 | 470 | 500 | 530 | 565 | 600 |
| Head tube (mm) | 99 | 119 | 134 | 134 | 154 | 178 | 199 |
| Standover (mm) | 697 | 724 | 754 | 780 | 808 | 839 | 869 |
| Handling | |||||||
| Head angle (°) | 70 | 70.50 | 71.25 | 71.75 | 71.75 | 72 | 72 |
| Seat angle (°) | 74 | 74 | 74 | 73.50 | 73.50 | 73.50 | 73.50 |
| Chainstay (mm) | 432 | 432 | 432 | 432 | 432 | 432 | 432 |
| Wheelbase (mm) | 1,019 | 1,026 | 1,032 | 1,039 | 1,060 | 1,075 | 1,092 |
| Fork offset (mm) | 55 | 55 | 55 | 50 | 50 | 50 | 50 |
| Trail (mm) | 69 | 66 | 61 | 63 | 63 | 61 | 61 |
Frame Details
Frame Weight
This frame weighs 1150g
Frame Material
Carbon Fiber
Forks
Specialized Diverge FACT 9r carbon, SWAT™ Door integration, Future Shock suspension, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc
Fork Material
The forks are made from Aluminium
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival ETAP AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival ETAP AXS
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle AXS
Cassette
SRAM Eagle PG-1230, 12-speed.
Cranks
SRAM Rival 1x Wide (165mm to 175mm)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB BSA 68
Chain
SRAM NX Eagle, 12-speed.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Front: Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 hub, 24h, DT Swiss Comp Race spokes, Rear: Roval Terra C, 25mm inner width carbon rim, 32mm depth, NEW DT 370 Star Ratchet hub, 24h, DT Swiss Comp Race spokes
Front Wheel Depth
32mm
Rear Wheel Depth
32mm
Tires
Front: Pathfinder Pro 2BR, Tan sidewall, 700x42, Rear: Pathfinder Pro 2BR, Tan sidewall, 700x42
Tire Type
Clincher
Max Tire Size: 47 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Front: SRAM Rival eTAP AXS, hydraulic disc, Rear: SRAM Rival eTAP AXS, hydraulic disc
Brake Rotors
160 mm front and 160 mm rear Center Lock rotors
Other Components
Saddle
Body Geometry Power Expert
Seatpost
Roval Terra Carbon Seat Post
Handlebars
Specialized Adventure Gear Hover, 103mm drop x 70mm reach x 12º flare
Bar Tape
Supacaz Super Sticky Kush
