Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 8.62 kg
The website average for Road bikes is 8.56 kg. This bike is 0.05 kg over the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Rival eTAP AXS
Wheelset
Roval Terra C
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 40 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
44 49 52 54 56 58 61 64This frame comes in 8 sizes, this is 2.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 44 | 49 | 52 | 54 | 56 | 58 | 61 | 64 |
|---|---|---|---|---|---|---|---|---|
| Sizing | ||||||||
| Rider height | 142–152 cm | 155–163 cm | 163–170 cm | 170–178 cm | 175–180 cm | 180–188 cm | 188–196 cm | 196–205 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||||
| Stack (mm) | 543 | 549 | 566 | 585 | 605 | 630 | 665 | 685 |
| Reach (mm) | 353 | 363 | 370 | 381 | 389 | 397 | 403 | 409 |
| Effective top tube (mm) | 503 | 518 | 533 | 550 | 569 | 582 | 599 | 614 |
| Seat tube (mm) | 365 | 410 | 438 | 465 | 485 | 512 | 545 | 575 |
| Head tube (mm) | 90 | 90 | 105 | 122 | 140 | 168 | 202 | 222 |
| Standover (mm) | 677 | 715 | 743 | 768 | 787 | 811 | 841 | 865 |
| Handling | ||||||||
| Head angle (°) | 69.30 | 70.80 | 71.50 | 72.30 | 73 | 73 | 73.50 | 73.50 |
| Seat angle (°) | 76 | 75.50 | 74.50 | 74 | 73.50 | 73.50 | 73 | 73 |
| Wheelbase (mm) | 993 | 994 | 997 | 1,005 | 1,015 | 1,030 | 1,043 | 1,057 |
Frame Details
Frame Weight
This frame weighs 950g
Frame Material
Carbon Fiber
Forks
Future Shock 3.2 w/ Smooth Boot
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Rival eTAP AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival eTAP AXS, 12-speed
Front Derailleur
SRAM Rival eTap AXS, braze-on.
Rear Derailleur
SRAM Rival eTAP AXS, 12-speed
Cassette
SRAM XG-1250.
Cranks
SRAM Rival AXS (165-175mm)
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB BSA 68 mm threaded
Chain
SRAM Rival, 12-speed with Flattop technology.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Roval Terra C
Front Wheel Depth
32mm
Rear Wheel Depth
32mm
Tires
S-Works Mondo 2BR, 700x32c
Tire Type
Tubeless
Max Tire Size: 40 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Rival AXS, hydraulic disc
Brake Rotors
160mm diameter on the front and 160mm diameter on the rear across both groupset versions
Other Components
Saddle
Body Geometry Power Expert
Seatpost
S-Works Pave Seat post
Handlebars
Specialized Hover Expert & Future Stem Pro
Bar Tape
Supacaz Super Sticky Kush
