Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.68 kg
The website average for Road bikes is 8.56 kg. This bike is 0.88 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano 105 R7170
Wheelset
DT Swiss R470
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
49 52 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Rider height | 155–163 cm | 163–170 cm | 170–175 cm | 175–180 cm | 180–188 cm | 188–196 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 514 | 527 | 544 | 565 | 591 | 612 |
| Reach (mm) | 375 | 380 | 384 | 395 | 402 | 408 |
| Effective top tube (mm) | 508 | 531 | 540 | 563 | 577 | 595 |
| Seat tube (mm) | 431 | 462 | 481 | 502 | 524 | 547 |
| Head tube (mm) | 109 | 120 | 137 | 157 | 184 | 204 |
| Standover (mm) | 705 | 734 | 753 | 775 | 798 | 823 |
| Handling | ||||||
| Head angle (°) | 71.75 | 72.50 | 73 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 75.50 | 74 | 74 | 73.50 | 73.50 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 973 | 975 | 978 | 991 | 1,005 | 1,018 |
| Fork offset (mm) | 47 | 47 | 44 | 44 | 44 | 44 |
| Trail (mm) | 63 | 58 | 58 | 55 | 55 | 52 |
Frame Details
Frame Weight
This frame weighs 699g
Frame Material
Carbon Fiber
Forks
FACT Carbon
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105 R7170
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105 R7170
Front Derailleur
Shimano 105 Di2 R7150, braze-on type (Official).
Rear Derailleur
Shimano 105 R7170, 12-speed
Cassette
Shimano 105 R7100, 12-speed (Official).
Cranks
Shimano 105 FC-R7100 (High confidence)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Threaded BSA BB
Chain
Shimano SLX/105 CN-M7100, 12-speed with Quick-Link (Official).
Wheel & Tire Details
Wheelset Name
DT Swiss R470
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
Turbo Pro, 60 TPI
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105, Hydraulic disc
Brake Rotors
160mm front and 160mm rear Shimano RT70 (or equivalent Center Lock) rotors
Other Components
Saddle
Body Geometry Power Sport
Seatpost
Roval Alpinist Carbon Seatpost
Handlebars
Specialized Shallow Drop
Bar Tape
Supacaz Super Sticky Kush
