Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Gravel
The style of riding intended for this bike
Bike Spec
Weight: 9.3 kg
The website average for Gravel bikes is 9.44 kg. This bike is 0.14 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM Apex XPLR
Wheelset
Giant P-X2 Disc wheelset
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 45 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
XS S M L XLThis frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Frame Details
Frame Weight
This frame weighs 160g
Frame Material
Carbon Fiber
Forks
Rigid Carbon with OverDrive Steerer & Cargo Mounts
Fork Material
The forks are made from Carbon Fiber
Cables: Semi Routed
Routed through the frame, not the bars
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Apex XPLR
Electric Groupset: No
This bike doesn't have electric gears
Shifters
SRAM Apex 1, 1x12
Front Derailleur
None
Rear Derailleur
SRAM Apex XPLR
Cassette
SRAM PG-1231 (Official)
Cranks
SRAM Apex 1 Wide DUB (170mm to 175mm by size)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM Apex D1 (12-speed flat-top design parameter) (Official)
Wheel & Tire Details
Wheelset Name
Giant P-X2 Disc wheelset, alloy
Front Wheel Depth
25mm
Rear Wheel Depth
25mm
Tires
Giant Crosscut Grip, 700x45c, tubeless
Tire Type
Tubeless
Max Tire Size: 45 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Apex hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Rotors
160mm front and 160mm rear, paired with Giant MPH rotors
Other Components
Saddle
Giant Grit
Seatpost
Post Moderne, dropper, 30.9mm, 30mm suspension XS:295mm, S:345mm, M:345mm, M/L:345mm, L:395mm, XL:395mmType: Dropper
Handlebars
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Bar Tape
Stratus Lite 3.0
