Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2022
The bike was released 4 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 9.07 kg
The website average for Road bikes is 8.56 kg. This bike is 0.50 kg over the average. Total bike weight may vary depending on frame size.
Groupset
Shimano 105 R7120
Wheelset
DT Swiss G540
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 38 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
48 50This frame comes in 2 sizes, this is 3.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 44cm | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | 150–158 cm | 155–163 cm | 163–170 cm | 170–175 cm | 175–180 cm | 180–188 cm | 188–196 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 540 | 555 | 570 | 585 | 605 | 630 | 665 |
| Reach (mm) | 353 | 363 | 368 | 376 | 384 | 392 | 398 |
| Effective top tube (mm) | 512 | 525 | 533 | 545 | 563 | 579 | 595 |
| Seat tube (mm) | 365 | 410 | 446 | 465 | 485 | 505 | 547 |
| Head tube (mm) | 90 | 100 | 112 | 125 | 143 | 170 | 205 |
| Standover (mm) | 682 | 715 | 743 | 762 | 783 | 805 | 844 |
| Handling | |||||||
| Head angle (°) | 70 | 71.50 | 72 | 72.75 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 74 | 74 | 74 | 74 | 73.50 | 73.50 | 73.50 |
| Chainstay (mm) | 413 | 413 | 413 | 415 | 415 | 418 | 418 |
| Wheelbase (mm) | 981 | 982 | 986 | 988 | 995 | 1,014 | 1,024 |
| Fork offset (mm) | 50 | 50 | 50 | 44 | 44 | 44 | 44 |
| Trail (mm) | 71.6 | 62 | 58.9 | 59.2 | 55.7 | 55.7 | 52.6 |
Frame Details
Frame Weight
This frame weighs 950g
Frame Material
Carbon Fiber
Forks
Future Shock 3.1 w/ Smooth Boot
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Shimano 105 R7120
Electric Groupset: No
This bike doesn't have electric gears
Shifters
Shimano 105 R7120, Hydraulic Disc
Front Derailleur
Shimano 105 R7000, braze-on type.
Rear Derailleur
Shimnao 105 R7100, 12-Speed
Cassette
Shimano 105, 11-34t (11-speed)
Cranks
Shimano 105 R7000 HollowTech II
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano BSA
Chain
KMC X11 Extra Lightweight, 11-speed with reusable missing link.
Wheel & Tire Details
Wheelset Name
DT Swiss G540 rim
Front Wheel Depth
23mm
Rear Wheel Depth
23mm
Tires
S-Works Mondo 2BR, 700x32c
Tire Type
Tubeless
Max Tire Size: 38 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano 105 Hydraulic Disc
Brake Rotors
160mm front and 160mm rear Shimano Center Lock SM-RT70 or equivalent rotors (Standard Specialized configuration for the endurance road disc platform)
Other Components
Saddle
Body Geometry Power Sport
Seatpost
S-Works Pave Seat post
Handlebars
Specialized Hover Comp
Bar Tape
Supacaz Super Sticky Kush
