Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
SRAM Force AXS
Wheelset
Reserve 42TA
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58 61This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Frame geometry | ||||||
| Stack (mm) | 496.1 | 520.2 | 544.6 | 567.5 | 590.7 | 610.7 |
| Reach (mm) | 368.7 | 376.5 | 383.3 | 391.1 | 400.3 | 408.3 |
| Effective top tube (mm) | 506 | 526 | 545 | 565 | 581 | 595 |
| Head tube (mm) | 89.6 | 109.3 | 132 | 156 | 182.8 | 203.7 |
| Standover (mm) | 707.6 | 747.1 | 773.8 | 811.6 | 820.7 | 839 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73 | 73 | 73 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73 | 73 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 973 | 974 | 973 | 988 | 1,005 | 1,020 |
| Fork offset (mm) | 58 | 52 | 46 | 46 | 46 | 46 |
| Trail (mm) | 57.3 | 57.3 | 57.3 | 57.3 | 57.3 | 57.3 |
Frame Details
Frame Weight
This frame weighs 919g
Frame Material
Carbon Fiber
Forks
Cervélo All-Carbon, Tapered Soloist Fork
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM Force AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Force AXS E1
Front Derailleur
SRAM Force AXS, 12-speed (Official). (Note: Excluded on regional 1x "Force XPLR AXS / Force 1 AXS" single-ring variants).
Rear Derailleur
SRAM Force AXS E1
Cassette
SRAM Force XG-1270, 10-33T, 12-speed
Cranks
SRAM Force AXS DUB (170mm to 175mm by size)
Power Meter: Yes
This bike comes with a power meter
Bottom Bracket
SRAM DUB, T47 BBright
Chain
SRAM Force, 12-speed (Official).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
F: Reserve 42TA, DT Swiss 350, 12x100mm, 24H R: Reserve 49TA, DT Swiss 350, 12x142mm
Front Wheel Depth
42mm
Rear Wheel Depth
49mm
Tires
Vittoria Corsa N.EXT TLR G2.0 700x29c
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM Force
Brake Rotors
160 mm front / 160 mm rear Centerlock rotors
Other Components
Saddle
Prologo Nago R4 PAS Tirox Lightweight
Seatpost
Cervélo SP27 Carbon
Handlebars
Cervélo HB13 Carbon, 31.8mm clamp
