eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2023
The bike was released 3 years ago
Screen
Yamaha Side Switch
Lights Included
No
Weight (inc battery): 26.4 kg
The website average for electric bikes is 22.99 kg. This electric bike is 3.40 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
SM: 40 CM, MD: 45 CM, LG: 50 CM, XL: 55 CM
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Jak 25 double-wall aluminium eyeleted rims, laced to Shimano MT 400-B (front) and MT 410 (rear) Centerlock hubs
Wheelset Size
27.5 inch
Tires
Schwalbe, Johnny Watts, 60-584, 27.5" x 2.35"
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
150 kg (330.7 lbs)
Drivechain Details
Groupset details
GX Eagle, SX Eagle
Drivechain type
Chain drive
Shifters
SRAM SX Eagle trigger shifter
Amount of gears
12 Gears
Rear Derailleur
SRAM GX Eagle
Front Derailleur
None
Cassette
SRAM PG 1210 Eagle, 11-50 teeth ratio
Cranks
Haibike Components The Cranks ++ aluminium arms
Chain
SRAM SX Eagle
Bottom Bracket
Integrated directly into the Yamaha PW-X 3 motor drive axle unit
Brakes
Brakes
Shimano hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
180 mm front / 160 mm rear
Shifters
SRAM SX Eagle trigger shifter
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
