eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Bosch Purion
Lights Included
No
Weight (inc battery): 26 kg
The website average for electric bikes is 22.99 kg. This electric bike is 3.00 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
SM, LG available
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Double-wall alloy rims (32-hole, 25 mm internal width) built on a Shimano TC 500 thru-axle front hub and the Shimano Nexus internal gear rear hub
Wheelset Size
700c
Tires
Schwalbe Big Ben, 28x2.00" (50-622), K-Guard puncture protection, reflective sidewalls
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
150 kg (330.7 lbs)
Drivechain Details
Groupset details
Nexus
Drivechain type
Belt Drive
Shifters
Shimano Nexus Revoshift, 5-speed twist shifter
Amount of gears
8 Gears
Rear Derailleur
None
Front Derailleur
None
Cassette
None
Cranks
Gates Bosch E-bike crankset equipped with a 46 T front sprocket
Chain
None
Bottom Bracket
Integrated within the Bosch Active Line Plus mid-drive motor casing
Brakes
Brakes
TRP hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
Shimano RT 30 centerlock rotors: 180 mm front and 160 mm rear
Shifters
Shimano Nexus Revoshift, 5-speed twist shifter
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
