Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.2 kg
The website average for Road bikes is 8.56 kg. This bike is 1.36 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Dura-Ace Di2
Wheelset
DT Swiss ERC1400
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 30 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
XXS XS S M L XL XXLThis frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | 150–162 cm | 160–170 cm | 168–176 cm | 174–182 cm | 180–188 cm | 186–194 cm | 192+ cm |
| Frame geometry | |||||||
| Stack (mm) | 500 | 513 | 531 | 552 | 571 | 592 | 611 |
| Reach (mm) | 370 | 375 | 378 | 380 | 399 | 401 | 420 |
| Effective top tube (mm) | 505 | 517 | 530 | 543 | 568 | 582 | 607 |
| Seat tube (mm) | 455 | 475 | 495 | 515 | 535 | 555 | 585 |
| Head tube (mm) | 90 | 100 | 115 | 135 | 155 | 175 | 195 |
| Handling | |||||||
| Head angle (°) | 70 | 71 | 72 | 72.50 | 72.50 | 73 | 73 |
| Seat angle (°) | 75 | 74.50 | 74 | 73.50 | 73.50 | 73 | 73 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 975 | 976 | 975 | 979 | 1,004 | 1,008 | 1,033 |
| Fork offset (mm) | 46 | 46 | 46 | 46 | 46 | 46 | 46 |
| Trail (mm) | 74.4 | 68.1 | 61.8 | 58.7 | 58.7 | 55.5 | 55.5 |
Frame Details
Frame Weight
This frame weighs 865g
Frame Material
Carbon Fiber
Forks
MAX technology Carbon Fiber, integrated cable routing, disc, 100x12 mm, flat mount
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Dura-Ace Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Dura-Ace Di2 R9250, 12-speed
Front Derailleur
Shimano Dura-Ace Di2 FD-R9250 (Official)
Rear Derailleur
Shimano Dura-Ace Di2 R9250, 12-speed
Cassette
Shimano Dura-Ace CS-R9200 (Official)
Cranks
Shimano Dura-Ace FC-R9200
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano Pressfit Road BB86
Chain
Shimano Dura-Ace CN-M9100 (Inferred from groupset / Official build specification)
Battery
Unknown
Wheel & Tire Details
Wheelset Name
DT Swiss ERC1400, carbon, 45 mm height
Front Wheel Depth
55mm
Rear Wheel Depth
55mm
Tires
Vittoria Corsa, Next TLR, 28-622, Folding | Vittoria Corsa, Next TLR, 28-622, Folding
Tire Type
Clincher
Max Tire Size: 30 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano BR-R9270, 12-speed | Shimano BR-R9270, 12-speed
Brake Rotors
Shimano RT-CL900 Center Lock rotors
Other Components
Saddle
fi'zi:k Vento Argo R5
Seatpost
FOCUS Aero Carbon Fiber, D-shape, 350 mm, set-back: 15 mm
Handlebars
Easton EC70 Aero, Carbon Fiber, drop: 125 mm, reach: 80 mm
Bar Tape
FOCUS Bartape SL
