Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.1 kg
The website average for Road bikes is 8.56 kg. This bike is 1.46 kg under the average. Total bike weight may vary depending on frame size.
Groupset
SRAM RED AXS
Wheelset
Zipp 404 Firecrest
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 30 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
XXS XXLThis frame comes in 2 sizes, this is 3.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | — | 156–166 cm | 163–174 cm | 171–182 cm | 179–189 cm | — | — |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 500 | 513 | 531 | 552 | 571 | 592 | 611 |
| Reach (mm) | 370 | 375 | 378 | 380 | 399 | 401 | 420 |
| Effective top tube (mm) | — | 520 | 536 | 551 | 569 | 582 | 601 |
| Seat tube (mm) | 440 | 470 | 500 | 520 | 540 | 560 | 590 |
| Head tube (mm) | 90 | 100 | 115 | 135 | 155 | 175 | 195 |
| Handling | |||||||
| Head angle (°) | 71 | 71.50 | 72 | 72.50 | 73 | 73 | 73.50 |
| Seat angle (°) | 74.50 | 74 | 73.50 | 73.50 | 73 | 73 | 72.50 |
| Chainstay (mm) | 410 | 410 | 410 | 410 | 410 | 410 | 410 |
| Wheelbase (mm) | 973 | 977 | 986 | 996 | 1,004 | 1,018 | 1,027 |
| Fork offset (mm) | 46 | 46 | 46 | 46 | 46 | 46 | 46 |
Frame Details
Frame Weight
This frame weighs 865g
Frame Material
Carbon Fiber
Forks
MAX technology Carbon Fiber
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
SRAM RED AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM RED HRD
Front Derailleur
SRAM RED AXS braze-on electronic front derailleur.
Rear Derailleur
SRAM RED AXS, 12-speed
Cassette
SRAM RED XG-1290 premium 12-speed cassette (Inferred from groupset specification).
Cranks
SRAM RED Carbon
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
SRAM DUB86, PF41
Chain
SRAM RED 12-speed Flattop chain.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
ZIPP 404 Firecrest, Carbon, 58mm, 23-622
Front Wheel Depth
58mm
Rear Wheel Depth
58mm
Tires
Vittoria Corsa G2.0, tubeless ready, 28-622 | Vittoria Corsa G2.0, tubeless ready, 28-622
Tire Type
Tubeless
Max Tire Size: 30 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount:
How these disc brakes are mounted
Brakes
SRAM RED E1 | SRAM RED E1
Brake Rotors
SRAM RED Paceline X | 160 mm front / 160 mm rear
Other Components
Saddle
fi'zi:k Vento Antares R1
Seatpost
FOCUS Aero Carbon Fiber, D-shape, set-back: 15 mm
Handlebars
Easton EC70 Aero, Carbon Fiber, 80 mm, 125 mm
Bar Tape
FOCUS Bartape SL
