Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 3 Years
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.4 kg
The website average for Road bikes is 8.56 kg. This bike is 1.16 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano Dura Ace Di2 FD-R9250-F, Braze-On
Wheelset
Newmen Streem A.49/54 Carbon
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
47 50 53 56 58 60 62This frame comes in 7 sizes, this is 1.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | 47 | 50 | 53 | 56 | 58 | 60 | 62 |
|---|---|---|---|---|---|---|---|
| Sizing | |||||||
| Rider height | 155–165 cm | 162–170 cm | 168–176 cm | 174–182 cm | 180–188 cm | 186–194 cm | — |
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||||
| Stack (mm) | 501 | 523 | 543 | 572 | 591 | 606 | 628 |
| Reach (mm) | 374 | 378 | 383 | 391 | 394 | 399 | 402 |
| Seat tube (mm) | 430 | 460 | 490 | 520 | 540 | 560 | 580 |
| Head tube (mm) | 95 | 115 | 135 | 165 | 185 | 200 | 220 |
| Standover (mm) | 732 | 757 | 782 | 809 | 827 | 845 | 863 |
| Handling | |||||||
| Head angle (°) | 71 | 71 | 72 | 72 | 72 | 72.50 | 72.50 |
| Seat angle (°) | 74.50 | 74.50 | 74 | 73.50 | 73.50 | 73 | 73 |
| Chainstay (mm) | 415 | 415 | 415 | 415 | 415 | 415 | 415 |
| Wheelbase (mm) | 981 | 996 | 1,003 | 1,018 | 1,034 | 1,040 | 1,056 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
C:62® Advanced Twin Mold Technology, Full Internal Cable Routing, Integrated Seat Post Clamp, Flat Mount Disc, Storage Box Option, AXH, 12x142mm
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano Dura Ace Di2 FD-R9250-F, Braze-On
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Dura Ace Di2 ST-R9270
Front Derailleur
Shimano Dura-Ace Di2 FD-R9250, Braze-On (Official)
Rear Derailleur
Shimano Dura Ace Di2 RD-R9250-D, 12-Speed, Electronic Shifting System
Cassette
Shimano Dura-Ace CS-R9200 (Official)
Cranks
FC-R9200 Hollowtech II
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
Shimano SM-BB71-41B, 86mm Pressfit
Chain
Shimano Dura-Ace / XTR CN-M9100, 12-Speed (Official)
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Newmen Streem A.49/54 Carbon, 21/24 Spokes, 12x100mm/12x142mm, Tubeless Ready
Front Wheel Depth
49mm
Rear Wheel Depth
54mm
Tires
Conti Grand Prix 5000 Kevlar, 28-622
Tire Type
Tubeless
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano Dura Ace BR-R9270, Hydr. Disc Brake, Flat Mount (160/160)
Brake Rotors
160 mm Front / 160 mm Rear, dual Shimano Centerlock disc rotors
Other Components
Saddle
ACID Nuance SLT Carbon
Seatpost
Agree C:62 Aero, Comfort Flex
Handlebars
ICR Cockpit System, Integrated Cable Routing, Aero Spacer System, Garmin Mount Interface
Bar Tape
ACID Bartape RD
