Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2023
The bike was released 3 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
Rival AXS
Wheelset
Zipp 303s
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 35 mm
This is the max tire size you can use
UCI Approved: Unknown
You can't use for official races
Sizing & Geometry
Frame Sizes
48 51 54 56 58This frame comes in 5 sizes, this is 0.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | S | M | L |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider height | 150–163 cm | 157–170 cm | 168–180 cm | 178–191 cm | 188–201 cm |
| Frame geometry | |||||
| Stack (mm) | 501 | 507 | 536 | 565 | 594 |
| Reach (mm) | 349 | 369 | 381 | 393 | 405 |
| Effective top tube (mm) | 507 | 529 | 550 | 571 | 592 |
| Seat tube (mm) | 487 | 500 | 506 | 518 | 533 |
| Head tube (mm) | 119 | 119 | 143 | 172 | 202 |
| Handling | |||||
| Head angle (°) | 69.50 | 71 | 72.70 | 73.20 | 73.20 |
| Seat angle (°) | 72.50 | 72.50 | 72.50 | 72.50 | 72.50 |
| Chainstay (mm) | 405 | 405 | 405 | 405 | 405 |
| BB drop (mm) | 71 | 69 | 69 | 69 | 69 |
Frame Details
Frame Weight
Unknown
Frame Material
Carbon Fiber
Forks
3T Fundi Integrale
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: No
You can use any bar and stem
Drivechain Details
Groupset name
Rival AXS
Electric Groupset: Yes
This bike has electric gears
Shifters
SRAM Rival AXS
Front Derailleur
SRAM Rival AXS wide or standard Braze-On electronic derailleur (Official).
Rear Derailleur
SRAM RIval AXS max 36T
Cassette
SRAM Rival XG-1250 (Inferred based on standard groupset assembly).
Cranks
SRAM Rival DUB (165 to 175mm by sizing)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
BB386EVO
Chain
SRAM Rival 12-speed Flattop chain (Inferred from standard groupset assembly).
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Zipp 303s
Front Wheel Depth
24.1mm
Rear Wheel Depth
24.1mm
Tires
Tire Type
Clincher
Max Tire Size: 35 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
SRAM Rival AXS Hydraulic Disc w/ SRAM 160mm rotor
Brake Rotors
160 mm front / 160 mm rear Centerlock disc configurations
Other Components
Saddle
Seatpost
3T STRADA SEATPOST FOR RITCHEY CLAMP
Handlebars
