Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
Released: 2024
The bike was released 2 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Groupset
105 Di2
Wheelset
Fulcrum Rapid Red 901
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 34 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
51 54 56 58This frame comes in 4 sizes, this is 1.56 less sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | 51 | 54 | 56 | 58 |
|---|---|---|---|---|---|
| Sizing | |||||
| Rider height | 150–163 cm | 157–170 cm | 168–180 cm | 178–191 cm | 188–201 cm |
| Wheel size | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | |||||
| Stack (mm) | 501 | 507 | 536 | 565 | 594 |
| Reach (mm) | 349 | 369 | 381 | 393 | 405 |
| Effective top tube (mm) | 507 | 529 | 550 | 571 | 592 |
| Seat tube (mm) | 487 | 500 | 506 | 518 | 533 |
| Head tube (mm) | 119 | 119 | 143 | 172 | 202 |
| Handling | |||||
| Head angle (°) | — | — | — | 73.20 | — |
| Seat angle (°) | 72.50 | 72.50 | 72.50 | 72.50 | 72.50 |
| Chainstay (mm) | 405 | 405 | 405 | 405 | 405 |
| BB drop (mm) | 69 | 69 | 69 | 69 | 69 |
Frame Details
Frame Weight
This frame weighs 1050g
Frame Material
Carbon Fiber
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
105 Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano 105 Di2 STR7170 12s
Front Derailleur
Shimano 105 Di2 FD-R7150 Braze-on (Confirmed Stock)
Rear Derailleur
Shimano 105 Di2 RD-R7150 12s
Cassette
Shimano 105 CS-R7100-12 (Inferred from groupset specification)
Cranks
Shimano 105 FC-R7100
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
BB386EVO
Chain
Shimano CN-M7100 12-Speed (Inferred from groupset specification)
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Fulcrum Rapid Red 900
Front Wheel Depth
40mm
Rear Wheel Depth
30mm
Tires
Pirelli PZero Road 700c
Tire Type
Clincher
Max Tire Size: 34 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Shimano BR-R7170 + 160mm RT70 front rotor + 160/140mm (depending on availability) RT70 rear rotor
Brake Rotors
160 mm front / 160 mm or 140 mm rear Shimano SM-RT70 Center Lock rotors
Other Components
Saddle
Selle Italia Model X
Seatpost
Strada Seatpost for Ritchey Clamp
Handlebars
3T Superergo Integrale LTD (XXS: 38cm - 51: 40cm - 54&56: 42cm - 58: 44cm)
