eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2026
The bike was released this year
Screen
Kynamic HMI
Lights Included
No
Weight (inc battery): 16.8 kg
The website average for electric bikes is 22.99 kg. This electric bike is 6.2 kg under the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
XS: <167 cm, SM: 165–175 cm, MD: 173–184 cm, LG: 182–192 cm, XL: 190+ cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
WTB STp i 27 rims (32 hole) laced to an alloy front hub (12 x 100 mm thru-axle) and the Kynamic rear hub motor (142 mm)
Wheelset Size
700c
Tires
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead
Frame Info
Frame Material
Aluminium
Suspension Type
No suspension
Foldable Frame
No
Max Payload
120 kg (264.6 lbs)
Drivechain Details
Groupset details
CUES
Drivechain type
Chain drive
Shifters
Shimano Cues 9-speed Rapidfire
Amount of gears
9 Gears
Rear Derailleur
Shimano Cues 9-speed
Front Derailleur
None
Cassette
Shimano Cues, 9-speed, 11-46 T
Cranks
Shimano Cues 170 mm with a 40 T or 42 T chainring and integrated chain guard
Chain
Shimano Cues 9-speed
Bottom Bracket
Kynamic BSA square taper (122.5 mm) with an integrated torque sensor
Brakes
Brakes
Tektro hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
180 mm front and rear
Shifters
Shimano Cues 9-speed Rapidfire
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
