eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2026
The bike was released this year
Screen
TQ LED display with Bluetooth & ANT+ connectivity
Lights Included
Yes
Weight (inc battery): 19.3 kg
The website average for electric bikes is 24.55 kg. This electric bike is 5.26 kg under the average. Total bike weight may vary depending on frame size.
Esystem & Battery
Motor Name
TQ-HPR 50
Motor Power
300 watts
Motor Torque
50 N.m
Sensor Type
Torque Sensor
Battery Capacity
360 wh
Claimed Max Range
45 miles (72.4 km)
Charge Time
3h 30m
Removable Battery
No
Sizing & Geometry
Min / Max Rider Height
XS | S 155–165 cm (5′1″–5′5″) | M 165–175 cm (5′5″–5′9″) | L 175–186 cm (5′9″–6′1″) | XL 186–197 cm (6′1″–6′5″)
Adjustable Sizing
Adjustable saddle height
Folded Dimensions
n/a
Wheel & Tire Details
Wheelset Name
Bontrager Paradigm, Tubeless Ready, 28-hole, 21 mm width
Wheelset Size
700c
Tires
Bontrager H2 Hard Case Lite, wire bead, 30 tpi, 700x40 mm
Frame Info
Frame Material
Aluminium
Suspension Type
No suspension
Foldable Frame
No
Max Payload
136 kg (299.8 lbs)
Drivechain Details
Groupset details
Shimano CUES U6000 10-speed
Drivechain type
Chain drive
Shifters
Shimano CUES U 6000, 10-speed
Amount of gears
10 Gears
Rear Derailleur
Shimano CUES U 6000 GS
Front Derailleur
None
Cassette
Shimano CUES LG 300, 11-48, 10-speed
Cranks
Shimano CUES U 6000 with a 42 T chainring
Chain
Shimano LG 500
Bottom Bracket
Integrated with the TQ-HPR 50 motor system
Brakes
Brakes
Shimano RS600 lever with RS405 hydraulic disc calipers and Shimano RT-MT800 / EM810 rotors (180 mm front / 160 mm rear)
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Shifters
Shimano CUES U 6000, 10-speed
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
