eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Bosch Kiox 300, smart system
Lights Included
Yes
Weight (inc battery): 23.1 kg
The website average for electric bikes is 24.55 kg. This electric bike is 1.46 kg under the average. Total bike weight may vary depending on frame size.
Esystem & Battery
Motor Name
Bosch Performance Line CX, Smart System
Motor Power
600 watts
Motor Torque
85 N.m
Sensor Type
Torque Sensor
Battery Capacity
545 wh
Claimed Max Range
60 miles (96.6 km)
Charge Time
3h 30m
Removable Battery
Yes
Sizing & Geometry
Min / Max Rider Height
XS | S 155–165 cm (5'1"–5'5") | M 164–176 cm (5'5"–5'9") | L 174–187 cm (5'8"–6'2") | XL 185–197 cm (6'1"–6'6")
Adjustable Sizing
Adjustable handlebar height, Adjustable saddle height
Folded Dimensions
n/a
Wheel & Tire Details
Wheelset Name
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width
Wheelset Size
27.5 inch
Tires
Schwalbe G-One, Performance, RaceGuard, with reflective strip, 57-584
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
136 kg (299.8 lbs)
Drivechain Details
Groupset details
Shimano CUES U4000 9-speed
Drivechain type
Chain drive
Shifters
Shimano CUES U 6000, 10-speed
Amount of gears
9 Gears
Rear Derailleur
Shimano CUES U 6000
Front Derailleur
None
Cassette
Shimano CUES LG 300, 11-48 T, 10-speed
Cranks
Pro Wheel alloy, 170 mm-175 mm (size dependent) with a 40 T steel chainring
Chain
Shimano LG 500 (Linkglide)
Bottom Bracket
Integrated with the Bosch Performance Line CX motor
Brakes
Brakes
Shimano MT401 lever with MT420 4-piston calipers and Shimano RT30 / EM300 rotors (203 mm front / 180 mm rear)
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
203 mm front rotor / 180 mm rear rotor
Shifters
Shimano CUES U 6000, 10-speed
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: 2 Years
Limited warranty website average: 3.12 years
The Allant+ 6 Lowstep is a magnificent city electric bike from the reputable brand, TREK. Designed for urban commuting with a hint of wild adventure, this machine features the state-of-the-art Bosch smart system, allowing you to pair your smartphone with your bike for a wide variety of functions such as tracking activities, planning routes and much more. Not only fuelled by your desire to ride, but also your desire to stay connected, this bike of ... Read More
